w w w. b i s s e l l . c o m
A
ssembly
Your steam&sweep Hard floor
cleaner assembles quickly and
easily. the only tool you will need
for assembly is a phillips head
screwdriver.
Your steam&sweep is packaged
with the following items:
Handle assembly
lower body with Water purification
system
maneuverable swivel Head
Removable Water tank
1 large phillips Head screw
1 small phillips Head screw
2 mop pads
attach handle to steam&sweep
Hard floor cleaner
1. Attach lower body to maneuverable
swivel head (If your Steam&Sweep came
with the swivel head already assembled
to the body, you may skip
this step).
2. Secure maneuverable swivel head
with small Phillips head screw. Tighten
until secure.
3. Slide handle assembly down into lower
body until it will go no further.
4. Secure the handle by placing the large
Phillips head screw through the screw
opening in the lower body and into the
rear of the handle assembly. Tighten with
screwdriver until secure.
5. Slide water tank onto lower body by
lining up vertical glides and gently
sliding tank into place.
Steam&Sweep assembly is now complete.
1.
3.
5.
4.
2.
5
