Страница 19
19
EN
4.3 Upgrade By RS-2321.
1. Press
keys to select among allcode,
main code, card, Radioback, keydate default db,
user db. The default option is allcode.
2. Press OK key at the Start button to start
checking serial port.
4.4 S/W Upgrade by OTA
1. Frequency: Use numeric keys to input the
proper value.
2. Bandwidth: Select among 6, 7, 8 MHz.
3. Down load PID: Use numeric keys to input the
proper value.
4. Start: Press OK key to start upgrading. If no
correct searching information, system will inform
“Collecting information”. You can press Exit
button to return to the previous window.System
will start upgrading after collecting information
successfully. Press OK key at the Download
button and press OK key at the Burnflash button
to start burning. After booting, press OK key at the
Reboot button to reboot.
4.5 Upgrade by USB
1. Upgrade File: Show the Upgrade File.
2. Upgrade Mode: Select between AllCode and Dump. When users switch
the upgrade mode, “Upgrade File” will show the corresponding file according
to the table below:
Upgrade Mode
File feature
All code:
File named as “*.abs”
Main Code:
File named as “*.bin”
Radio back:
File named as “*.m2v”, the
picture will be used as both
radio back and menu back.
Default db:
File named as “*.bin”
Select the upgrade mode and upgrade file, then you can start upgrade by USB.
