Juice Extractor JE-8500
Please read the safety instructions carefully before using this
appliance. Please retain the instructions for future refer- Please retain the instructions for future refer- Please retain the instructions for future refer- Please retain the instructions for future refer- Please retain the instructions for future refer-
ence. ence. ence. ence. ence.
DESCRIPTION OF THE
APPLIANCE
Pic. A:
1. Small pusher
2. Large pusher
3. Feeder tube
4. Grater/filter
5. Pulp container
6. Anti-drip system (juice stopper)
7. Juice spout
8. Safety clamps
9. Body
10.Rubber foot
11.Driving shaft
12.Three-position switch «0/I/II»
BEFORE USE
! Remove all packing materials from the ap-
pliance.
! Wipe the appliance body with soft damp cloth,
thoroughly wash all the appliance parts com-
ing into contact with food.
OPERATING INSTRUCTIONS
Assembly
1. Place the juice extractor on dry level surface.
Make sure than the switch (12) is in «0»
position.
2. Install the pulp container (5), by matching
the juice spout (7) with the groove on the
body (9).
3. Put the grater/filter (4) inside the pulp container (5) so that it
completely fits into the driving shaft (11) until click. Check that
the grater/filter (4) rotates freely. Put the feeder tube (3) above.
4. Insert the feeder tube (3) into the pulp container (5) matching the
projections on the feeder tube (3) with the safety clamps (8).
5. Lift the safety clamps (8) and put them down so that they lock on
the projections of the feeder tube (3).
Note: The juice extractor has a safety system. If the safety
lock (8) is not securely fastened, the appliance will
not operate.
