4
Instruction Manual
• Before removing memory card stop
recording. Press on the card until a click to
remove it.
• Motion detector recording is available after
you switch on this item in the setting menu (see
“Setup“ paragraph below for more details). The
unit will go to recording mode if there is image
motion in front of the lens. If there is no motion
within 1, 3 or 5 minutes, then the unit will
automatically go to standby mode. In standby
mode, if there is motion again, the unit will go
to recording mode.
Playback mode
In record mode press MODE button to enter
playback mode. The upper left corner of screen
will display MOVIE. Press
button to go to
6-thumbnail mode. Press or buttons
to choose video files. Press button to play
the selected file. Press button to stop and
resume playback. During playback, press
or buttons to adjust sound volume.
Photo mode
In record mode press MODE button twice
to choose the photo mode. The upper left
corner of screen will display PHOTO. Press
button to take a photo. Press button
to go to 6-thumbnail mode. Press or
buttons to choose photo files.
HDMI output
Connect the HDMI output of this unit to an
external audio-video device (e.g. car TV) with
the supplied HDMI cable. Now this unit can be
used as high-quality digital signal source for
the external device.
Setup
Press MODE button thrice to display the
setting menu. In the menu press or
buttons to select settings. Press button to
go to adjustment of the selected setting; select
options with
or buttons and press
button to confirm. Press MODE button to
exit from the menu.
Some menu items may be in grey color,
in this case they are not adjustable. The menu
in your unit may be changed without prior
notice and hence be different from the menu
described below.
• Resolution: select resolution of the
recording video.
• Video quality: H/M/L. Select video quality.
• Record overwrite: no/2 min/5 min/15min.
Deactivate or select cycled recording period.
• Motion detection: no/1 min/3 min/5 min.
Deactivate or select motion detector activation
period.
• Power on record: On/Off. If On is selected,
the unit will automatically start recording in 3
seconds after the engine is started.
• Power off delay: On/Off. Activate or
deactivate auto switch-off of this unit after the
car engine is shut down.
• Image size: 3m/5m/8m/12m. Select photo
size.
• Image quality: Super fine/Fine/Normal.
Select photo quality.
• Self capture: on/off. If On is selected, the
shooting will be performed with 10-seconds
delay.
• Sequence capture: capture1/capture3.
Select how many pictures will be taken by 1
pressing of the button.
• Auto capture: off/30 sec/60 sec. Select the
period after which a new photo will be taken
automatically.
• Language: select a language of the menu.
• TV type: NTSC/PAL. Select the color
system.
• Time stamp: off/date/time/date and time.
Select display of date and time in the video and
photo.
• Time setup: Set current month, day, year,
hour and minute with / buttons and
button to select parameter.
• Beep sound: On/Off. Activate or deactivate
the sound of pressing buttons.
