13
15
SPECIFICATION
DC 14.4 NEGATIVE GROUND
4 ~ 8 OHM (4 SPEAKER)
43WATTS 4CH (At 4 ohm)
FM:87.5 ~ 108MHz AM:531 1602kHz
FM:87.5 ~ 108MHz AM:522 ~ 1620KHz
FM:87.5 ~ 108MHz AM:520 ~ 1620KHz
FM:6dBu S/N:30dB AM:24dBu S/N:20dB
COMPACT DISC DIGITAL AUDIO SYSTEM
COMPACT DISC (12cm STD)
1.2m/S ~ 1.4m/S(500rpm ~ 200rpm)
20Hz ~ 20kHz
0.1%
90dB
70dB
70dB at 1kHz
FM : 58dB AM:52dB
FM : 30dB
RADIO SECTION
CDP SECTION
Power requirement
Speaker impedance
Rated output power
Tuning range
(Europe)
(Latin America)
Usable sensitivity
S/N Ratio
Stereo separation
SYSTEM
DISC
RPM
Frequency response
Total harmonic distortion
Dynamic Range
S/N Ratio
Channel separation
How to Operate the Remocons
1. Power ON/OFF button ( POWER )
Press the POWER button to turn it on.
2. Mode Change button ( MODE )
Press the MODE button to change modes.
3. Manual and automatic selection
Press this button to tune the broadcasting stations for RADIO/fast
forward and rewind of TAPE/track up,down and track fast search in
CD . ( SEEK )
- Manual selection of broadcasting stations ( TUNE )
It works in the dual mode when you listen to radio.
Press this button for less then 2 sec, it is in the manual tune mode;
press
button to reduce the frequency and press
button to in-
crease the frequency of stored preset buttons 1-6.
- Automatic selection of broadcasting stations ( SEEK )
It works in the dual mode when you listen to radio.
Press this button for more then 2 sec, it is in the automatic seek
mode; press
button to scan frequency lower / higher than
marked currently frequency and to stop at a broad-casting station
automatically. (Moving frequency appears on the V.F.D..)
13
HANDLE REMOCONS
REMOCON INFORMATION
POWER ON/OFF BUTTON ( POWER )
MODE CHANGE BUTTON ( MODE )
MANUAL, AUTOMATICAL TUNING / TAPE FF, REW / DISC
TRACK BUTTON ( SEEK )
VOLUME CONTROL BUTTON ( VOL )
SOUND MUTE BUTTON ( MUTE )
1. Handle Remocon
How to Operate the Remocons
1. Power ON/OFF button ( POWER )
Press the POWER button to turn it on.
2. Mode Change button ( MODE )
Press the MODE button to change modes.
3. Manual and automatic selection
Press this button to tune the broadcasting stations for RADIO/fast
forward and rewind of TAPE/track up,down and track fast search in
CD . ( SEEK )
- Manual selection of broadcasting stations ( TUNE )
It works in the dual mode when you listen to radio.
Press this button for less then 2 sec, it is in the manual tune mode;
press
button to reduce the frequency and press
button to in-
crease the frequency of stored preset buttons 1-6.
- Automatic selection of broadcasting stations ( SEEK )
It works in the dual mode when you listen to radio.
Press this button for more then 2 sec, it is in the automatic seek
mode; press
button to scan frequency lower / higher than
marked currently frequency and to stop at a broad-casting station
automatically. (Moving frequency appears on the V.F.D..)
13
HANDLE REMOCONS
REMOCON INFORMATION
POWER ON/OFF BUTTON ( POWER )
MODE CHANGE BUTTON ( MODE )
MANUAL, AUTOMATICAL TUNING / TAPE FF, REW / DISC
TRACK BUTTON ( SEEK )
VOLUME CONTROL BUTTON ( VOL )
SOUND MUTE BUTTON ( MUTE )
1. Handle Remocon
How to Operate the Remocons
1. Power ON/OFF button ( POWER )
Press the POWER button to turn it on.
2. Mode Change button ( MODE )
Press the MODE button to change modes.
3. Manual and automatic selection
Press this button to tune the broadcasting stations for RADIO/fast
forward and rewind of TAPE/track up,down and track fast search in
CD . ( SEEK )
- Manual selection of broadcasting stations ( TUNE )
It works in the dual mode when you listen to radio.
Press this button for less then 2 sec, it is in the manual tune mode;
press
button to reduce the frequency and press
button to in-
crease the frequency of stored preset buttons 1-6.
- Automatic selection of broadcasting stations ( SEEK )
It works in the dual mode when you listen to radio.
Press this button for more then 2 sec, it is in the automatic seek
mode; press
button to scan frequency lower / higher than
marked currently frequency and to stop at a broad-casting station
automatically. (Moving frequency appears on the V.F.D..)
13
HANDLE REMOCONS
REMOCON INFORMATION
POWER ON/OFF BUTTON ( POWER )
MODE CHANGE BUTTON ( MODE )
MANUAL, AUTOMATICAL TUNING / TAPE FF, REW / DISC
TRACK BUTTON ( SEEK )
VOLUME CONTROL BUTTON ( VOL )
SOUND MUTE BUTTON ( MUTE )
1. Handle Remocon
ДИСТАНЦИОННОЕ УПРАВЛЕНИЕ
■
ОБЩИЕ СВЕДЕНИЯ
Кнопки дистанционного управления
1.
1
КНОПКА ВКЛЮЧЕНИЯ/ВЫКЛЮЧЕНИЯ ("POWER")
2
КНОПКА ПЕРЕКЛЮЧЕНИЯ РЕЖИМОВ ("MODE")
3
КНОПКИ РУЧНОЙ, АВТОМАТИЧЕСКОЙ НАСТРОЙКИ/
ПЕРЕМОТКИ ВПЕРЕД-НАЗАД/ВЫБОРА ДОРОЖКИ
ДИСКА ("SEEK")
4
КНОПКИ РЕГУЛИРОВКИ ГРОМКОСТИ
("VOL")
5
КНОПКА ВЫКЛЮЧЕНИЯ ЗВУКА ("MUTE")
Как пользоваться дистанционным управлением
1. Кнопка включения/выключения ("POWER")
Для включения аудиосистемы нажать кнопку "POWER".
2. Кнопка выбора режимов ("MODE")
Для выбора режимов нажать кнопку "MODE".
3. Кнопки ручной и автоматической настройки
Нажимать эти кнопки для настройки на частоту радиостанции при
работе аудиосистемы в режиме радиоприемника, для быстрой пе-
ремотки вперед и назад при воспроизведении кассеты и для смены
дорожек при работе в режиме CD-проигрывателя ("SEEK")
- Ручная настройка радиостанций
При включении аудиосистемы в режиме радиоприемника данная
настройка может быть активирована в двойном режиме.
При кратковременном (менее 2 секунд) нажатии одной из этих
кнопок, будет активирован режим ручной настройки; нажать кноп-
ку "", чтобы перейти к предварительно настроенной радиостан-
ции с меньшей частотой, и нажать кнопку "", чтобы перейти к
предварительно настроенной радиостанции с меньшей частотой.
- Автоматический выбор передающих радиостанций
При включении аудиосистемы в режиме радиоприемника данная
настройка может быть активирована в двойном режиме.
При нажатии и удержании (более 2 секунд) кнопки активируется
режим автоматической настройки; нажать кнопку "" или "",
при этом будет осуществлен автоматический поиск радиостанций
путем уменьшения или увеличения частоты соответственно. (Из-
менение частот отображается на дисплее)
•
•
•
•
•
•
