ENGLISH
6
PARAMETER SETTING
DSL Protocol and Multiplexing type • PPP over ATM VCMUX (RFC2364)
• PPP over ATM LLC (RFC2364)
• Bridged IP over ATM LLCSNAP (RFC1483)
• Routed IP over ATM LLCSNAP (RFC1483)
• Bridged IP over ATM VCMUX (RFC1483)
• Routed IP over ATM VCMUX (RFC1483)
• Classical IP over ATM (RFC1577)
• PPP over Ethernet VCMUX (RFC2516)
• PPP over Ethernet LLCSNAP (RFC2516)
Modulation • G.Dmt
• G.Lite
• ANSI T1.413
Peak Cell Rate • Line rate
• ______ Kbps
Virtual Path Identifier (VPI)
Virtual Channel Identifier (VCI)
IP Address and Subnet mask • Automatically set by ISP
• Assigned manually
Address:
Subnet mask:
DNS Address • Automatically set by ISP
• Use the following
Preferred DNS Server:
Alternative DNS Server:
Default gateway address
User name and Password for PPP connections Username:
Password:
6. Screens pop up to report the progress of the installation. You do not need to click anything until you are
prompted to plug in your modem.
Connect your modem to the computer.
7. When the installation has successfully completed, click Finish to close the wizard.
8. If your connection is using PPPoE or PPPoA protocol, the ZyXEL ADSL Link icon will appear on your desktop.
Double click on the icon to activate connection to your ISP.
