1.4 Left View
The following is a brief description of the left side of the notebook.
NO. Item Function
1 External
Monitor Port
The external monitor port allows you to
connect an external monitor.
2 LAN (RJ-45)
Port
The LAN port is designed to support a
10/100/1000 Base-T standard RJ-45 plug.
3 HDMI Port
The HDMI port allows you to connect a
video device such as an HD television,
projector, or HD display to your computer
for outputing a high definition signal.
4 e-SATA/USB
combo port
The e-SATA/USB combo port allows you to
connect an external device such as an external
hard disk drive or optical drive that use serial
ATA as well as any type of USB device.
5 Multi Card
Reader
The memory card reader offers the fastest
and most convenient method to transfer
pictures, music and data between your
notebook and flash compatible devices
such as digital cameras, MP3 players,
mobile phones, and PDAs.
6 Express Card
Slot
The Express Card Slot allows you to install
one Type-II Express Card Slot.
1.5 Right View
The following is a brief description of the right side of the notebook.
1 2 3 5 6 7 8 4
NO. Item Function
1 Microphone
Jack
The microphone jack allows you to connect
an external microphone.
2 Headphone
Jack
The headphone jack allows you to connect
headphones or external speakers and
amplifiers.
3 USB 2.0 Port
The USB port allows you to connect
universal serial bus devices. It supports
v2.0 of the USB standard, which allows
data exchange rates as high as 480 Mb/s.
4 Optical Disc
Drive
The optical drive allows you to play back
and write media discs such as CDs &
DVDs.
5
Optical Drive
Activity
Indicator
This light flickers to indicate activity when
the ODD is playing a media disc or is being
accessed by the operating system.
1 2 3 5 6 4
