Connecting to the monitor output terminal ( t ) – Инструкция по эксплуатации Sony KV-HW212
Страница 26
26
Sony KV-HW212M95 Group H4 (
GB
, RU)_2-177-672-12 (1)
Additional Information
DVD player
TV rear panel
Component video
cable
(not supplied)
Audio cable
(not supplied)
L
R
R
1
L
Y
C
B
C
R
(MONO)
(MONO)
Connect
To (on the DVD player)
Y (green)
Y
C
B
(blue)
C
B
, P
B
, C
b
or B-Y
C
R
(red)
C
R
, P
R
, C
r
or R-Y
Connecting to the component video input terminal (
)
TV rear panel
Audio system
L
R
R
1
L
Y
C
B
C
R
(MONO)
(MONO)
VCR
Audio/Video
cable
(not supplied)
Connecting to the monitor output terminal ( T )
Notes
• If your DVD player can output interlace and progressive mode signals, select the interlace
output when connecting to
(component video input) on your TV. Your TV can receive
either 525i/60Hz or 625i/50Hz interlace signals.
• Some DVD player terminals may be labeled differently:
• If you select “DVD” on your TV screen, the signal from the T (monitor output) jacks will not
be output properly. This does not indicate a malfunction.
