Sony KV-32LS60K - Инструкция (Страница 21)

21
GB
Specifications
Additional Information
TV system:
Depending on your country selection:
B/G/H, D/K
Colour system:
PAL, SECAM
NTSC 3.58, 4.43 (only Video In)
Channel Coverage:
VHF: E2-E12
UHF: E21-E69
CATV: S1-S20
HYPER: S21-S41
D/K: R1-R12,
R21-R69
Picture Tube:
Flat Display FD Trinitron WIDE
32” (approx. 82 cm. measured
diagonally)
Rear Terminals
1 / 1 21-pin scart connector
(CENELEC standard)
including audio/video
input, RGB input, TV
audio/video output.
2 / 2 21-pin Scart connector
(CENELEC standard)
including audio / video
input, RGB input,
monitor audio/video
output.
3 / 3 21-pin Scart connector
(SMARTLINK) (CENELEC standard)
including audio / video
input, S video input,
selectable audio / video
output and Smartlink
interface.
audio outputs (Left/
Right) - phono jacks
S
Design and specifications are subject to change without notice.
Ecological Paper - Totally Chlorine Free
Side Terminals
4 S Video input – 4 pin DIN
4 video input – phono jack
4 audio input – phono jacks
headphones jack
Sound Output:
2 x 20 W (music power)
2 x 10 W (RMS)
Woofer:
30 W (music power)
15 W (RMS)
Power Consumption:
130 W
Standby Power Consumption:
0.3 W
Dimensions (w x h x d) :
Approx. 892 x 565 x 584 mm.
Weight:
Approx. 62.2 Kg.
Accessories supplied:
1 Remote Control (RM-932)
2 Batteries (IEC designated)
Other features:
• 100 Hz picture
• Teletext, Fastext, TOPtext (250 page TEXT
memory)
• Sleep Timer
• Smartlink (direct link between your TV set
and a compatible VCR. For more
information on Smartlink, please refer to
the Instruction Manual of your VCR).
• TV system Autodetection.
• Dolby Virtual.
• BBE.
• Auto Format.
• ACI (Auto Channel Installation).
S
01GBKV32LS60K.fm Page 21 Friday, February 21, 2003 6:43 PM
