3. Using the clipper for hair cutting and thinning
TIP: Cut the hair for demanded length in stages, start form bigger length.
Insert appropriate comb attachment (small – (IV) or big (V)).
Set the desired length of hair/beard with the cutting length adjustment knob – (3). The length of clipped hair is indicated (In millimetres) at the length
indicator on the comb attachment.
Switch the device on moving the ON/OFF switch – (4) to 1 position.
Cut only small areas. –
Move the clipper slowly along hair. –
Hold the device so, that the comb attachment is laid flat. –
Always start the cutting from the neck upwards or from the forehead and temples upwards to the top of head. –
In order to thin the hair turn the hair thinning knob
(2) left to position; the thinning attachment in-tegrated with
cutting head (1) shall be moved up from the housing.
You can reduce the hair volume with this feature. It provides a modern, changed look without the change of
hair length.
4. Cutting hair without attachment
WARNING: The cutting head (1) is very sharp. Injury hazard!
You can cut the hair in uniform length of 1–2 mm without comb attachment.
For clipping the hairline of bristle and whiskers, neck shaving:
Move the hair clipper slowly along hair. –
Turn the device so, that the back part was directed upwards. –
Place the edge of the cutting head – (1) without comb attachment on desired length of bristle hairline.
Move down the clipper in operation. –
5. Comb attachments inserting/replacing
It is possible to select one of two comb attachments:
The small attachment can cut hair for the length of: 4 mm, 7 mm, 10 mm, 13 mm, and 16 mm. ●
The big attachment can cut hair for the length of: 18 mm, 21 mm, 24 mm, 27 mm, and 30 mm. ●
Select the attachment according to the length of cutting.
–
Insert it into the side guiding grooves of the clipper (you will hear a click). –
Make sure that the two side protrusions are visibly locked in fastening inlets of the comb attachment (see the picture –
beside).
Replace one attachment removing it and inserting another as described above. –
Turn left the cutting length adjustment knob – (3), to increase the length of cutting or right to reduce it.
Element for
thinning hair
