3
➀ ➁ ➂ ➃ *OPTION
1. Slide the free end of the extension wand into the nozzle tube.
2. Slide the narrow end of one extension wand into the other extension wand.
3. Slide the extension wand into the handle end of the hose.
4. Slide the hose clamp into the suction inlet of the unit.
* SOPTION : Ajusting the telescopic tubes (depending on model).
ASSEMBLING THE VACUUM-CLEANER SO THAT IT IS READY FOR USE
USAGE OF FLOOR NOZZLE
➀
➁
Select the carpet indicator ➀ when cleaning carpets.
Select flat surface indicator ➁ when cleaning the floors, tiles, etc.
FOR RUG / FLOOR SELECTOR
Before use make sure that the position of the selector is in the right position for the type of surface to be
cleaned.
FOR UNIVERSAL BRUSH
Use the floor nozzle for all cleaning surfaces.
NOTE: For optimum efficiency, clean floor brush with crevice tool.
