Using the 3D Function
You can enjoy 3D movies and games on your TV. The 3D effects function enables you to view 3D images using special 3D glasses.
Connections ❑
1. Connect a HDMI/DVI cable between the HDMI IN 2(DVI) jack on the TV and the PC output jack on your computer.
. Connect a 3.5mm Stereo Audio Cable between the DVI AUDIO IN jack on the TV and the Audio Out jack of the sound card on your
computer.
3. Connect the Emitter to the 3D SYNC OUT port on the rear panel of the TV.
4. Turn the TV on and set the source of the TV to HDMI2/DVI.
For more information on the 3D glasses (including the Emitter), refer to the user manual of your 3D glasses.
Adjust the PC resolution: - PS42B450B/PS42B451B : 1024 x 768@60Hz
- PS50B450B/PS50B451B : 1024 x 768@60Hz, 1360 x 768@60Hz
Optimum PC resolution for PS50B450B/PS50B451B is 1360x768. When 1024x768 signal is connected in 3D mode, the picture will
be shown in 4:3 format with left and right side grey bars appeared.
The 3D IR Emitter communicates with the 3D glasses.
Therefore, the 3D IR Emitter should be located near the 3D glasses.
It is activated when the HDMI or DVI input signal is RGB, and DVI Sound is supported. activated when the HDMI or DVI input signal is RGB, and DVI Sound is supported. when the HDMI or DVI input signal is RGB, and DVI Sound is supported.
When the power is turned on or off, the mode changes to the default ( Off) and the Format is saved.
To use the 3D Effect function, a graphics card supporting 3D or 3D software is required.
The 3D glasses and the Emitter must be manufacturer by the same company.
If you play a game or watch TV while wearing the 3D glasses for long periods of time, you may experience eyestrain or a headache.
3D glasses (including the Emitter) not manufactured by Samsung may not be supported.
If you find the screen flickering while the 3D function is used, change the environmental lighting darker or turn off the fluorescent
lamp to watch the screen for its best condition.
N
N
N
N
N
N
N
N
N
N
N
The appearance of the 3D glasses (including Emitter) may differ depending on the model of your glasses.
N
3D Glasses
(Not supplied)
3D IR Emitter
(Not supplied)
PC
TV Rear Panel
3.5mm Stereo Audio Cable

HDMI/DVI Cable (Not supplied)
1
Continued...
