11
ENGLISH
Sound adjustments
You can select a preset sound mode suitable to
the music genre (C-EQ: custom equalizer).
1
2
Indication (For)
BAS TRE LOUD
(bass) (treble) (loudness)
USER
(Flat sound)
00 00 OFF
ROCK
(Rock or disco music)
+03 +01 ON
CLASSIC
(Classical music)
+01 –02 OFF
POPS
(Light music)
+04 +01 OFF
HIP HOP
(Funk or rap music)
+02 00 ON
JAZZ
(Jazz music)
+02 +03 OFF
Adjusting the sound
You can adjust the sound characteristics to your
preference.
1
2
Indication, [Range]
BAS* 4 (bass), [–06 to +06]
Adjust the bass.
TRE* 4 (treble), [–06 to +06]
Adjust the treble.
FAD* 5 (fader), [R06 to F06]
Adjust the front and rear speaker balance.
BAL (balance), [L06 to R06]
Adjust the left and right speaker balance.
LOUD* 4 (loudness), [LOUD ON or LOUD OFF]
Boost low and high frequencies to produce a
well-balanced sound at low volume level.
VOL (volume), [00 to 30 or 50* 6 ]
Adjust the volume.
* 4 When you adjust the bass, treble, or loudness,
the adjustment you have made is stored for
the currently selected sound mode (C-EQ)
including “USER.”
* 5 If you are using a two-speaker system, set the
fader level to “00.”
* 6 Depending on the amplifier gain control
setting. (See page 13 for details.)
Preset values
Ex.: When “ROCK” is selected
