46
ENGLISH
Menu items Selectable settings, [reference page]
Disc Setup 2
* 3
Speaker Level You can adjust the output level of the activated speakers ( ☞
see “Speaker Size” on page 45), monitoring the test tone.
• Front Left/Center/Front Right/Rear Right/
Sub Woofer* 4 /Rear Left: adjust the output level of each
speaker in the range of –10dB to +10dB; Initial 00.
• Press and hold ENT to turn on and off the test tone—Test
Tone: ON, OFF.
Speaker Distance* 5 You can adjust the speaker output timing.
• Front Left/Center/Front Right/Rear Right/Rear Left:
adjust the speaker distance from the listening position in
the range of 15 cm/6 inches to 600 cm/240 inches in 15-
cm/6-inch step. [Initial: 120 cm (for center speaker), 150
cm (for the other speakers)]
• Press and hold DISP to change the measuring unit—cm and
inch.
Tuner
AF Regional When the received signals from the current station become
weak...
Off : Cancels—not selectable when “DAB AF” is set to
“On.”
AF Regional: Switches to another station broadcasting the
same programme. (REG indicator lights up.)
AF: Switches to another station. The programme may
differ from the one currently received (AF indicator
lights up),
☞ [14].
TA Volume 00 to 30 or 50* 6 ; Initial 15, ☞ [13].
Program Search Off, On, ☞ [14]
* 3 Selectable only for “DISC” or “SD.”
* 4 This subwoofer level setting takes effect only when surround is activated ( ☞ also page 49).
* 5
Not selectable when only the front speakers are activated.
* 6 Depends on the amplifier gain control.
Adjusts the speaker distance
Adjusts the speaker level
Selects the speaker
Selects the speaker
