17
Turntable installation
a. Never place the glass tray upside down. The glass tray
should never be restricted.
b. Both glass tray and turntable ring assembly must always be
used during cooking.
c. All food and containers of food should be always placed on
the glass tray for cooking.
d. The glass tray rotates clockwise; this is normal.
e. If glass tray or turntable ring assembly cracks or breaks, con
tact your nearest authorized service
centre.
Remove all packing material and accessories. Examine the oven for any damage such as dents or
broken door. Do not install if oven is damaged.
Countertop
Cabinet: Remove any protective film found on the cabinet surface.
Do not remove the light brown oven cover that is screwed to the oven cavity to protect the
magnetron.
1. Select a level surface that provide enough open space for the intake and/or outlet vents.
A minimum clearance of 3.0 inch (7.5cm)
is required between the oven and any adja
cent wall. One side must be open.
(1) Leave a minimum clearance of 12 inch
(30cm) above the oven.
(2) Do not remove the legs from the bottom of
the oven.
(3) Blocking the intake and/or outlet open
ings can damage the oven.
(4) Place the oven as far away from radios and
TV as possible.Operation of microwave
oven may cause interference to your radio or TV reception.
2. Plug your oven into a standard household outlet. Be sure the voltage and the frequency is the
same as the voltage and the frequency on the rating label.
WARNING: Do not install oven over a range cooktop or other heat pro
ducing appliance. If installed could be damaged and the warranty would
be void.
The accessible surface may be hot during operation.
Hub (underside)
Glass
tray
Turntable shaft
Turntable ring assembly
Installation
7,5 cm
7,5 cm
30 cm
Open
