1
En
■Using as 2ch stereo speakers
Better stereo images will be obtained when the speakers are
slightly angled in towards the listeners.
■Using as front speakers and surround
speakers in a surround system
Position the speakers on both sides of the TV. The positioning of
speakers is important, since this dictates the overall sound quality
of the surround system. Set up the speakers on the basis of your
listening position by following the owner’s manual supplied with
your amplifier.
And mount the speakers on a wall or place the speakers on a shelf.
Determine the best position by following the owner’s manual
supplied with your amplifier.
■To mount the speakers on a wall by using
the attached mounting bracket
Fasten screws into a firm wall or wall support as shown in the
figure, and hang the holes of the mounting bracket on the
protruding screws.
* Make sure that the screws are secured in the narrow sections
of the holes.
Note
Placing this unit too close to a CRT TV set might impair
picture color or create a buzzing noise. Should this happen,
move the speaker away (more than 20 cm (7-7/8”)) from the
TV set.
When using a PDP or LCD TV, it would not happen.
WARNING
• NS-B210 weighs 1.6 kg (3 lbs. 8 oz.). Do not mount it on thin
plywood or a wall with soft surface material. If mounted,
the screws may come out and the speaker may fall. This may
damage the speaker, or cause personal injury.
• Do not install the speaker on a wall with nails, adhesives, or
any other unstable hardware. Long term use and vibrations
may cause it to fall.
• To avoid accidents resulting from tripping over loose
speaker cables, fix them securely to the floor or wall.
PLACING THE SPEAKERS
For NS-B210
NS-B210
Front
NS-C210
NS-B210
Surround
Subwoofer
You can also use the screw holes on the bottom of the speaker
for installing the speaker using a commercially available
speaker bracket (if you do not use the attached mounting
bracket).
Diameter. 3.5 to 4 mm
(1/8” to 3/16”)
3 mm
(1/8”)
Min.
20 mm
(13/16”)
Tapping screw (3.5-4 mm) (1/8” to 3/16”)
(Available at the hardware store)
Wall or wall
support
26 mm
(1”)
60 mm (2-3/8”)
Screw holes
Diameter: 6 mm (1/4”)
Hole Depth: 14 mm (9/16”)
