4
REMOTE CONTROL
AUTO
HEAT
COOL
DRY
FAN
SPEED
AIR
SWING
AUTO
HEAT
COOL
DRY
FAN
SPEED
AIR
SWING
Press the remote control’s button
1
TO TURN ON OR OFF THE UNIT
• Please be aware of the OFF indication on the remote
control display to prevent the unit from starting/stopping
improperly.
2
TO SET TEMPERATURE
• For heat, cool and dry modes, the range of temperature
for selection is 16˚C~30˚C.
• Operating the unit within the recommended temperature
could induce energy saving.
COOL mode : 26˚C ~ 28˚C.
HEAT mode: 20˚C ~ 24˚C.
DRY mode : 1˚C ~ 2˚C lower than room temperature.
3
TO SELECT OPERATION MODE
AUTO mode - For your convenience
• Unit selects the operation mode according to the room
temperature.
• Once auto mode is selected, the unit will operate at the
standard setting temperature.
• To change the standard setting temperature, press for
“
” or for “
”.
Room
temperature
Operation
mode
Standard setting
temperature
(+2°C)
(–2°C)
23°C & above
Cool
25°C
27°C
23°C
Below 23°C
Dry
22°C
24°C
20°C
Below 20°C
Heat
21°C
23°C
19°C
HEAT MODE - TO ENJOY WARM AIR
• In heat mode, it may take a while for the unit to warm up.
The POWER indicator blinks during preheating.
COOL mode - To enjoy cool air
• Use curtains to screen off sunlight and outdoor heat to
reduce power consumption during cool mode.
DRY mode - To dehumidify the environment
• Unit operates at low fan speed to give a gentle cooling
operation.
Maximum distances: 8m
3
4
5
Remote Control display
1
2
4
TO SELECT FAN SPEED (3 OPTIONS)
FAN SPEED
• For AUTO, the indoor fan speed is automatically adjusted
according to the operation mode.
5
TO ADJUST VERTICAL AIRFLOW DIRECTION
(5 OPTIONS)
AIR SWING
• Keeps the room ventilated.
• In COOL/DRY mode, if AUTO is set, the louver swing up/
down automatically.
• In HEAT mode, if AUTO is set, the louver fix at
predetermined position.
INDICATOR
(Green)
(Orange)
