18
ENGLISH
1
2
Select a sound mode.
To display the rest
3
Exit from the setting.
Storing your own sound modes
You can adjust the sound modes and store your
own adjustments in memory.
• When
appears on the display, you can
move back to the previous display by pressing
number button 3.
1
Follow steps 1 and 2 above.
2
Select a frequency range.
3
Adjust the sound elements of the
selected frequency range.
1 Use 5 / ∞ to adjust the level.
2 Press number button 2 ( ),
then turn the control dial to select the
frequency.
3 Press number button 2 ( ), then
turn the control dial to select the band
width.
Sound
elements
Range/selectable items
Low Mid High
Level –06 to
+06 –06 to
+06 –06 to
+06
FREQ
(Frequency) 60 Hz
80 Hz
100 Hz
200 Hz 500 Hz
1 kHz
1.5kHz
2.5kHz 10 kHz
12.5kHz
15 kHz
17.5kHz
Q (Band
width) Q1.0
Q1.25
Q1.5
Q2.0 Q0.5
Q0.75
Q1.0
Q1.25 Fix
4
Repeat steps 2 and 3 to adjust other
frequency ranges.
5
Store the adjustments.
