Sony XR-F5100EE - Инструкция (Страница 13)

13
Other Functions
You can also control the unit (and optional CD/
MD units) with a rotary commander
(optional) .
Using the rotary commander
First, attach the appropriate label depending on
how you want to mount the rotary commander.
The rotary commander works by pressing
buttons and/or rotating controls.
By pressing buttons
By rotating the control
Rotate and release to:
– Locate the beginning of tracks on the tape.
– Tune in stations automatically.
– Skip tracks on the disc*
1 .
Rotate, hold, and release to:
– Fast-wind the tape.
– Find a station manually.
– Fast-forward/reverse a track*
1 .
Tip
To start playback while fast-winding the tape, press
(MODE) .
By pushing in and rotating the control
Push in and rotate the control to:
– Receive preset stations.
– Change discs during CD (MD) playback*
1 .
During playback of a CD containing MP3
files
* 3
Push in and repeat rotating quickly to:
– Change discs one by one.
Push in, then rotate and hold to:
– Change albums* 3 .
*1 Only if the corresponding optional equipment is
connected.
*2 If your car has no ACC (accessory) position on the
ignition key switch, after turning off the ignition, be
sure to press and hold
(OFF) until the display
disappears.
*3 Available only when an optional CD unit with the
MP3 file control function is connected, and MP3 file
is played.
Press To
(SOURCE) Change the source
(Radio/Tape/CD*
1 /MD* 1 )/
Power on
(MODE) Change operation
(Radio band/Tape playback
direction/CD unit*
1 /MD
unit* 1 )
(ATT) Attenuate the sound
(OFF)* 2 Stop playback or radio
reception/Power off
(SEL) Adjust and select
(DSPL) Change the display item
SEL
DSPL
MODE
SEL
DSPL
MODE
OFF
Rotate the VOL control
to adjust the volume.
(SOURCE)
(SEL)
(ATT)
(DSPL)
(OFF)
(MODE)
continue to next page t
SEEK/AMS
control
PRESET/DISC
control
