Laundry Guide
RECOMMENDATION
1.
It’s better to rub the stains on
clothes neckline, cuffs with a
small amount of detergent
before washing.
2.
Dissolve the washing powder
with warm water in a container
before putting into the wash
tub.
3.
Use the special fabric detergent
to wash the fine fabric clothes.
4.
For effective cleaning, stop the
wash after 1 minute, let the
laundry soak for 15 minutes
before continuing the washing
process.
5.
Use minimum water level for
washing, increasing the water
level during the rinsing
process, thus allowing better
cleaning effect.
WASHING INSTRUCTIONS
1. WASH
a. Set the “water inlet selector” to
“wash” position.
b. Turn “Function” to normal wash.
c. Turn on the tap and fill up water until
the selected level, then turn the tap off.
d. Pour detergent into wash tub.
e. Load the laundry into the wash tub.
f. Set the wash timer to selected time
and the machine will start washing.
g. Transfer the washed laundry from
wash tub to the spin tub after done.
h. Turn “Function” to “Drain” to empty
the wash tub.
2. RINSE
* To save time and water, spin-dry the
laundry before rinsing *
a. Set the “water inlet selector” to
“wash”, fill-up water until the selected
water level, then turn off the tap.
b. Transfer the spin-dried laundry back
to wash tub.
c. Set “Wash timer” to 5 minutes and
start rinsing.
d. After rinsing, transfer laundry to spin
tub and spin-dry for 1-2 minutes (If the
rinsed water is dirty, please drain it and
repeat the step a and b till water is
clean).
* Rinse Option
(a) You may rinse laundry with the tap
on until the water is clean.
(b) Then transfer laundry to spin tub to
spin-dry.
3. SPIN-DRYING
A. Place the rinsed clothes evenly in the
spin tub and cover with the spin cover.
B. Close the safe lid and the spin tub lid.
C. Turn the “Spin Timer” to selected
timing and spin dry starts.
NOTE:
1.
If the spin tub vibrates badly,
please turn off the “spin timer”
and spread the clothing evenly
once the tub has stopped
spinning.
2.
Turn off and unplug the
machine when not in use.
4. DRAINING
a. Place the drain hose into the drain
outlet on the floor before draining.
b. Turn “Function” to “Drain” position
after washing process and drain water
from wash tub.
c. When spin-drying, close the spin tub
cover, set the spin timer to selected
time, place the drain hose into drain
outlet on the floor, set the “Function” to
the “Drain” position, then the water is
drained.
THE CLEANING METHOD OF FILTER
(If do not clean the filter, it will influence
the filtering effect).
1.
Pull the filter out from the slot
on the wash tub.
2.
Open the filter, clean the dust
gauze with water and get rid of
the crumbs.
3.
Close the filter, insert the filter
back to the slot on the wash
7
tub.
TROUBLE SHOOTING
Problem
Reason
Solution
Power
supply cut-
off or
switch turn
off
Check power
supply/
Turn on the
switch
The
pulsator
can not
rotate
Transmission
belt burst
Assemble
the
transmission
belt
Pulley belt is
loose
Tighten the
belt
Pulsator is
blocked by
something
Remove the
blockage
The
pulsator
rotates
slowly
Belt is loose
Tighten the
belt or
replace it
The motor’s
screw is
loose
Tighten the
belt and the
screw
Abnormal
noise and
vibration
The clothes
in the spin-
dry tub is
unbalanced
Place the
clothes
evenly
There is
something
between the
pulsator and
the wash tub
Remove it
Water
leaking
Wash tub is
not
Tighten it
from wash
tub
tightened
Switch
contact is
loose
Adjust the
contactor or
the switch
Spin-dry
tub is not
rotating
Spin-dry
tub’s screw
or shaft
coupling is
loose
Tighten the
screw
Spin-dry
tub’s shaft is
twisted by
external
material
Remove the
external
material
Brake
dragline is
loose
Tighten the
dragline
The spin-
tub is not
draining
Something
drops
between the
spin-tub and
out basket
Remove it
·
Attention: If above problems can
not be solved, please call
qualified repair personnel.
Technical Data:
Power:
360W
Rated Voltage:
220-230V
Rated Frequency:
50Hz
Rated Current:
1.6А
Maximum Capacity:
4,5kg
Dimensions:660x395x790 mm
Set
Semi-automatic washing machine 1
Instruction manual
with warranty book
1
Package
1
ENVIRONMENT FRIENDLY
DISPOSAL
You can help protect the
environment!
Please remember to respect
the local regulations: hand in
the non-working electrical
equipment to an appropriate
waste disposal center.
The manufacturer reserves the right
to change the specification and
design of goods.
