4
· Connect he iron to a suitable mains
supply outlet
· Turn the temperature control button
to the “• • ”, or “• • •” "MAX" setting
· The pilot light turns on when the
required temperature is reached. The
iron is ready for use.
· Turn the steam knob to the required
position, steam starts coming out from
the holes in the sole plate.
· Notice: With conventional steam
ironing, water may leak from the sole
plate if too low temperature has been
select. If this happens turn the
temperature control to the advised
position. Steam will recommence as
soon as die appropriate temperature has
been reached.
BURST OF STEAM
This function provides an extra amount
of steam to remove stubborn wrinkles.
· Fill the iron with water.
· Turn the temperature control to the
position 'MAX".
· The iron is ready for use.
· Press the burst of steam knob once
· Steam will penetrate into the garment
removing the wrinkles.
· Wait a few seconds before pressing
the steam control knob wrinkles again
when there are stubborn wrinkles.
· Usually all wrinkles can be removed
within three pressings.
DRY IRONING
· Connect the iron to a suitable mains
supply outlet.
· Ensure that the steam control knob is
in position “0”.
· Select the setting on the temperature
control.
· When the pilot light turns off, the
required temperature is reached. The
iron is ready to use.
TO LET THE IRON HEAT UP AGAIN
Pick up the iron or move it slightly.
The red shot-off pilot goes out. If the
temperature of the soleplate drops
below the set ironing temperature, the
temperature pilot goes on.
If the pilot light goes on after you have
move the iron, wait for it to go out
before you start ironing.
If the pilot light does not go on after
you move the iron, the soleplate still
has right temperature and iron is ready
for use.
SELF CLEAN FUNCTION
The Self Clean function can remove any
scale or impurities.
Use the self-clean function once every
two weeks. If the water in your area is
very hard, the self-clean function should
used more frequently.
· Make sure the appliance is unplugged.
· Set the Variable steam control knob
to position "0" (=no steam).
· Fill the water tank to the maximum
level.
· Select the maximum ironing
temperature.
· Put the plug in the wall socket.
· Unplug the iron when the temperature
pilot light has gone out.
· Hold the iron over the silk, press and
hold die self-clean button and gently
shake the iron.
· (Steam and boiling water will come
out of the soleplate. Impurities and
flakes (if any) will be flushed out.)
· Release the self-clean button as soon
as all water in the tank has been used
up.
· Repeat the self-clean process if the
iron still contains a lot of impurities.
CARE AND CLEANING
1. Turn the Temperature Control Dial
to OFF, then disconnect the iron from
the wall outlet and cool it down
completely.
2. Deposits and other residues on the
sole plate can be removed with a cloth
soaked in a vinegar/water solution.
3. The casing may the wiped with a
damp cloth and then polished with a dry
one.
4. Never use any abrasives to clean
the sole plate.
5. Keep the sole plate smooth, avoid
contact with metal objects.
6. When you have finished ironing or
you are leaving iron unattended:
- turn the steam control knob to
position “0”.
- stand the iron upright
- disconnect the iron from the wall
outlet.
Do not allow children to touch the iron
or the power cord whom ironing.
7. Do not immerse die iron or the
cord into water or any other liquid.
8. Do not touch hot metal parts, hot
water or steam. These parts become hot
and may cause burns. Take care if you
turn die iron upside downs: there may
be not hot water in the tank. The plug
and cord should not be allowed to touch
the hot sole plate. Let the iron cool
down completely before taking it away.
Roll the power cord around the iron for
storage.
9. Disconnect die iron from the wall
outlet for filling in water or when you
remove the water after use.
10. The iron is for household use only.
5
12. Save the instruction manual for
future reference
Notes:
· Some parts of the iron have been
slightly greased and as result the iron
may smoke slightly when switched on
for the first time. It will not happen
again after a few uses.
· Before using for the first time, remove
any protective films or stickers from the
sole plate and the cabinet. Then clean
the sole place with a soft cloth.
· When using the iron for the first time,
test it on an old piece of fabric to ensure
that the sole plate and water tank are
completely clean.
CHOICE OF WATER
· This iron can be used with normal tap
water.
· If the water in your area is
particularly hard, it is advisable to use
distilled or demineralized water.
· Do not use chemically descaled water
or any other liquids for refilling.
HOW TO FILL IN WATER
· Set the Steam Control Knob “0” and
the temperature Control Dial to OFF.
· Unplug the iron from the wall outlet.
· Pour water into the water inlet.
· Fill up to the maximum level “MAX” of
the water tank.
LABEL KIND OF
TEXTILE
FIBRE
MATERIAL
Synthetic Acrylic
Modacryc
Polypropylene
Po|yurethane
Synthetic Acetate
Triacetate
Synthetic Cupro
Polyamide
(Nylon)
Polyester
Viscose
(Rayon)
Silk Silk
Wool Wool
Cotton Cotton
Linen Linen
SETTING THE TEMPERATURE
· Insert the plug in the wall socket and
stand the iron upright.
· Turn the temperature control knob to
the desired temperature setting.
· The desired temperature has been
reached when the pilot light has turned
off.
· The pilot light will turn on and off
from time after time, indicating that the
selected temperature is being
maintained.
Specification
Power: 2200 W
Working voltage: 220-230 V
Working frequency: 50 Hz
Rated сurrent 10 A
Set
Iron 1pc
Instruction manual with
warranty book 1pc
Package 1pc
ENVIRONMENT
FRIENDLY DISPOSAL
You can help protect the
environment!
Please remember to
respect the local
regulations: hand in the
non-working electrical
equipments to an
appropriate waste disposal centre.
The manufacturer reserves the right to
change the specification and design of
goods.
