No liability can be accepted for any

damage caused by noncompliance with

these instructions or any other improper

use or mishandling.

The iron should always be turned to

"min" before plugging or unplugging

from the mains outlet. Never pull the

cord to disconnect from the mains:

instead, grasp plug and pull to

disconnect.

Burns can occur from touching hot

metal parts, hot water or steam, use

caution when you turn a steam iron

upside down-there may be hot water in

the reservoir.

If the iron is not operating normally,

disconnect from the power supply and

contact the nearest authorized service

agent.

Your iron is designed to rest on the

heel. Do not leave the iron unattended

when switched on. Do not place the iron

on an unprotected surface even if it is

on its heel rest.

FILLING WITH WATER

Ensure the iron is disconnected

from the power supply.

Turn the steam control knob to

position "0".

Fill with water through water filling

inlet. (Do not exceed main level mark

on the water tank.)

SETTING THE TEMPERATURE

* Synthetics-Silk

** Wool

*** Cotton- Linen

Stand the iron upright.

Set temperature control to ironing

temperature.

Inset the mains plug into the main

supply.

After the indicator light has gone

out and come on again, you may start

ironing.

The indicator light will go out from

time to time during ironing.

STEAM-IRONNING

Set the temperature control to

position** for moderate steam and to

***

for

maximum

steam.

With

conventional steam irons, water may

leak from the soleplate if a too low

temperature has been selected.

Ensure that there is enough water

in the water reservoir.

Stand the iron on its heel.

Insert the mains plug into the wall

socket.

Wait a little while for the indicator

light to go out and come on again.

See the variable steam knob to

adjust the steam.

BURST OF STEAM

By pressing button an intense

"Burst "of steam is emitted from the

soleplate.

To prevent water leaking from the

sole plate, do not keep the steam

control button depressed for more than

5 seconds.

SPRAY SETTING

At any temperature by pressing the

spray button a couple of time the

laundry can be damped down.

Ensure that there is enough water

in the water reservoir.

DRY IRONING

Turn the variable steam knob to the

position "O"(=no steam).

STORAGE

Remove the mains plug from the

wall socket.

Pour and remaining water out of the

water reservoir.

Set the steam knob to no steam

position.

Stand the iron upright and let it

coot down sufficiently.

CLEANING

Before cleaning the iron ensure it is

disconnected from the power supply and

has completely cooled down.

Deposits on the soleplate may be

removed with a rough cloth soaked in a

vinegar/water solution.

The casting may be wiped with a

damp cloth and then polished with a dry

one.

Do not use abrasives on the

soleplate.

Keep the sole plate smooth. Avoid

hard contact with metal objects.

SELF CLEANING

It is important to apply "self-cleaning"

at least every two weeks to remove

impurities etc.

The harder the water the more the

iron should be self-cleaned.

Open the filling funnel and fill the

water reservoir up to the MAX position,

then close the filling funnel.

Set the temperature control to

MAX.

Insert the mains plug into the wall

socket.

Allow the iron to heat up until the

temperature pilot light goes out.

Then set temperature control dial to

position MIN.

Hold the iron horizontally over the

sink, then remove the variable steam

control knob from the body enabling the

iron to self clean.

Boiling water and steam will now be

ejected from the holes in soleplate.

Impurities are washed away with it.

Move the iron forwards and backwards

while this happened.

Set the steam control to "O"

position, when the water reservoir has

become empty.

Repeat self-cleaning if you notice

that much impurity or other has been

washed out.

Move the iron over a (preferably)

old piece of cloth. This is to ensure that

the soleplate will be dry during storage.

Unplug and allow the iron to cool

clown before storing it.

Specification

Power:

2000 W

Rated Voltage:

220-230 V

Rated Frequency:

50 Hz

Rated Current:

9 A

Set

Iron

1pc

Instruction Manual

1pc

Warranty Book

1pc

Package

1pc

ENVIRONMENT FRIENDLY

DISPOSAL

You can help protect the

environment!

Please

remember

respect

the

local

regulations: hand in the

non-working

electrical

equipments

appropriate waste disposal

centre.

The manufacturer reserves the right

to change the specification and

design of goods.

УТЮГ

Уважаемый покупатель!

Поздравляем Вас с приобретением

изделия торговой марки “Saturn”.

Уверены, что наши изделия будут

верными и надежными

помощниками в Вашем домашнем

хозяйстве.

Не подвергайте устройство резким

перепадам

температур.

Резкая

смена температуры (например,

внесение устройства с мороза в

теплое

помещение)

может

вызвать

конденсацию

влаги

внутри устройства и нарушить его

работоспособность

при

включении. Устройство должно

отстояться в теплом помещении не

менее 1,5 часов. Ввод устройства в

эксплуатацию

после

транспортировки производить не

ранее, чем через 1,5 часа после

внесения его в помещение.

Описание:

Кнопка распыления воды

Кнопка усиленной подачи пара

Регулятор степени отпаривания

Окошко для наполнения воды

Распылитель воды

Декоративная вставка

Подошва утюга

Регулятор температурного режима

Прозрачный резервуар для воды

10. Индикатор работы
