5
DESCRIPTION
B ottom cover
C ontrol panel
H ot plate
T op cover
CONTROL PANEL
FUNCTION INSTRUCTION
1. Press “ ” button to start the unit.
LED display will show “00”.
2. Heating function setting: press
FUNCTION button once, LED will
displays corresponding P8 as the
default power is 1800W, and the
HEAT indicator will light up, it
means entering heating mode, and
power can be adjust by pressing
“ ” or “ ” button to the
following value: P1(400W)-
P2(600W)- P3(800W)- P4(1000W)-
P5(1200W)- P6(1400W)-
P7(1600W)-P8(1800W).
3. Warming function setting: press
FUNCTION button again, LED
displays H6 as the default
temperature is 240℃, and the
WARM indicator will light up, it
means entering warming mode, and
the warming temperature can be
set by pressing “ ” or “ ”
button to the following
value:H1(60℃)-H2(100℃)-
H3(140℃)-H4(180℃)-H5(220℃)-
H6(240℃).
4. Timer function setting: under mode
of HEAT or WARM, press TIME
button once to enter timer setting
which is used for setting the time to
shut off the power, at this time the
LED displays 10, the default time is
10 minutes.
1. Within 5s press “ ” or “ ”
button to set time, the
maximum set time is 99
minutes.
2. The “ ” and “ ” buttons can be
hold down to scroll through the
digits, or pressed and released
to advance one digit at a time.
Note: If the time is not adjusted
within 5s, the time setting will
be finished.
3. Press the TIMER button to
confirm the time, and buzzer
sound will be heard.
5. The unit will stop automatically
when no button is pressed within
2h.
OPERATION
1. Insert power cord into a separate
appropriate socket, and buzzer
sound will be heard once, LED
display will show “- -”, indicating
the unit is powered.
2. Place the pan on the center of the
hot plate.
3. Press “ ” button, LED display will
show “00”.
4. Press the FUNCTION button once,
LED display will show corresponding
setting, and at the time the fan
starts running, the default power of
left unit is P8 (1800W), which can
be adjusted by pressing “ ” or
“ ” button, the LED display
shows “E0” if the pan is not placed
in position and buzzer sound will be
heard at an interval of 3 second.
The appliance will return under the
standby mode immediately if you
place the pan in position within 60s,
if you do not place the pan in
position within 60s, after 60s, the
appliance will also return under
standby mode.
5. Press FUNCTION button again to
enter WARM setting. The default
temperature is 240°C, the LED
display shows “H6”，which can be
adjusted by pressing “ ” or “ ”
button, when the temperature rises
to the set value, the program will
enter the automatic protection.
Note: you can reset the function by
pressing FUNCTION button at any
time during operation.
6. Under mode of HEAT or WARM, you
can set the time to shut-off the
power by pressing TIME button.
1. After timing, power and time
will cycle to display. You can
adjust the power by pressing
6
“ ” or “ ” button.
2. After timing, press “ ” or
“ ” button to adjust the
temperature, temperature and
time will cycle to display.
Note: under timing shut-off mode,
the unit can be shut off by pressing
“ ”button, after being shut off,
the timing shut-off setting will be
cancelled, and at the next start the
previous set time will not be saved.
7. When time runs out, the unit will
stop operating automatically and all
indicators will be extinguished.
Note: the operation process can be
terminated at any time by pressing
the “ ” button. When cooking
program is ended the integrated
cooling fan will continue running for
60 seconds.
8. After cooking, unplug the mains
cord from the power outlet.
OPERATION PRINCIPLE
The operation principle of induction
cooker is achieved by the current
produced by magnetic field induction
which electron circuitry board produces
alternate magnetic field, when the pan
bottom containing metal material is
placed on the hotplate, the pan will
immediately cut the alternate magnetic
field and then the metal part of pan
bottom produces the current
(whirlpool), it makes iron molecule run
irregularly at high speed, following the
collision and friction between molecules
produce heat energy which makes the
appliance heat promptly, so that the
purpose of cooking food is achieved.
PRODUCT ADVANTAGE
1. High efficiency, saving energy and
environmental protection: cooker
body is heating part itself, so heat
efficiency is very high and save
energy greatly, when cooking food
with induction cooker, there is no
visible fire, smoke and waste gas,
bear environment protection effect,
safe and clean.
2. Wider applicable voltage range: the
unit can adjust automatically the
wattage according to the power
voltage, so that it avoids the
trouble resulting from voltage
fluctuation.
3. Perfect safety protection function:
the unit has safe protection function
for over voltage, lower voltage or
sudden voltage change. However
normal over temperature function is
quick and accurate.
4. Accurate and perfect inspection for
pan quality and no-load protection
function: the unit can inspect
whether the material or size of pan
is applicable. When the pan is
moved away, the unit stops heating
immediately and after 10s the
power is cut off. No matter how the
pan is moved away quickly or
slowly, it causes no damage to
induction cooker.
5. Start self-diagnosis function and 2h
timing shut-off function: it can
define whether induction cooker
operation are appropriate, that
induction cooker is not being
operated for long time and will be
considered forgotten, it will shut of
the power automatically after 2h,
so it makes using it safely.
6. Multi-section wattage adjustment
and multi-section temperature
control: convenient and agile use,
in addition temperature control
compensation feature makes
setting the temperature more
exact.
7. Multi-heating function: perform
different cooking demand according
to different power.
SAFETY PROTECTION EQUIPMENT
1. Over voltage protection and lower
voltage protection. When power
voltage is too high or low, induction
cooker will compensate voltage
automatically and adjust output
power.
2. Small metal part protection. For
small iron metal parts which
diameter is less than 80mm, no
power is outputted to avoid
abnormal heating.
3. No pan or improper pan protection.
When no utensil is placed on the
hotplate or the utensil is deviated
greatly from the center, or the
material of the utensil is not
applicable, the power will not be
output and buzzer sound will be
heard to alert until appropriate
utensil is put in place.
4. Over temperature protection.
When the temperature of top
hotplate is too high, induction
cooker will stop automatically
power output and long buzzer
sound will be heard to alert until
the temperature returns to normal.
