4
-Do not cook on Broken Cook-Top – If
cook-top should break, cleaning solutions
and spillovers may penetrate the broken
cook-top and create a risk of electric
shock.
-Clean Cook-Top with Caution – If a wet
sponge or cloth is used to wipe spills on a
hot cooking area, be careful to avoid
steam burn, some cleaners can produce
noxious fumes if applied to a hot surface.
New hot plates are with the newly
technology with far infrared heating.
For household and indoor use only
Save These Instructions
Please turn on the switch at the side
panel(see the follow picture), to power on
the unit, it is used to all of the models
with electric infrared cooker.
Guide to the Hot plates
How to Use:
1. POWER-ON: Make sure connect the
appliance to a suitable socket and
turn on, the buzzer sounds that
makes you know the connecting is
right. In this time, the appliance is on
ready mode. P.S.: the appliance is
power-on without heating.
2. STAND BY/OFF: Press the key" "
more than 1.5 seconds and the
buzzer sounds then press the
the digital display "P1" , in this time ,
the appliance is start to heating.
When the Hot plates is working, it can
be shut by press key " ".
3. UP, DOWN: The default setting for
heating at first is gear 1. Press the
key " "&" "can adjust
gears。The digital screen will display
"P1~P12".
4. SET-TEMP: Press the key " ",
the gears and temperature will be
exchange by automatically when it is
working. Under the setting TEMP
mode, press the key " "&"
"can adjust the temperature.
5. SET TIME: Press the key " ",
the time of heating can be set freely.
It will plus five minutes when you
press " ". It will reduce one
minute when you press" ". The
time will twinkle ten seconds and then
time is countdown. When is no time,
the Hot plates will be shut
automatically.
6. LOCK: During your operation, in
order to avoid children to touch press
the key " ". When you press the
key " ", the buzzer sounds that
the key is start. Under lock mode,
except press the key " " and
" " the other key is not to use. If
out of lock mode, please press the
key " ", the buzzer sounds that
the key is unlocked.
7. Do not remove the plug from the
socket when you just finish using the
5
appliance. Softly touch " "that
make the appliance stop heating.
About eight or ten minutes later, you
can remove the plug.
The inner fan can still work to eliminate
heating and increase ability of safe.
Attention: the appliance will be shut
automatically if it is not be use in two
hours.
Please do not heating without pot or with
empty pot!
The pot diameter can be used are range
from 180-280MM!
Please make sure the pot are flat and are
put on the heating place!
When heating or after heating, the
ceramic plate is hot, The power cord and
other non heat-resistant items are
strictly prohibited close or across the hot
place!
Cleaning and maintenance
· Unplug the power plug prior to
cleaning the device. Do not use any
caustic cleaning agents and make sure
that no water penetrates the device.
· To protect yourself from electric
shock, never immerse the device, its
cables and the plug in water or other
liquids.
· After cool down, wipe off the ceramic
field with a damp cloth or use a mild, non-
abrasive soap solution.
· Wipe off the casing and the operating
panel with a soft cloth or a mild detergent.
· Do not use any petrol products to not
damage the plastic parts and the
casing/operating panel.
· Do not use any flammable, acidy or
alkaline materials or substances near the
device, as this may reduce the service life
of the device and lead to deflagration
when the device is turned on.
· Make sure that the bottom of the
cookware does not scrape across the
surface of the ceramic field.
· Make sure that the device was
properly cleaned before storing it in a dry
place.
· No user serviceable parts inside.
Repair should be done by authorized
service personnel only.
The code of fault
reasons code
thermocouple cutting-out E1
thermocouple opening E2
the wrong with fan E3
thermistors opening E4
thermistors cutting-out E5
over heating inner cooker E6
relay cutting-out E7
relay opening E8
the inner temperature is out
of control
E9
Specifications
Power:
2000 W
Rated Voltage: 220-230 V
Rated Frequency: 50 Hz
Rated Current: 9 A
Set
INDUCTION COOKER
1
INSTRUCTION MANUAL WITH
WARRANTY BOOK 1
PACKAGE 1
Environment friendly disposal
Service life – 2 years
