4
6. Switch
Instruction for Use of Juicer

Cut the fruit or vegetable into pieces
and make sure that they can go through
the guide hole.

Put the separating trough on the base
and turn it tight clockwise. Put the filter
into position on the connector and then
put on the transparent cover and lock
the cover, the inner lock switch will be
connected automatically.

Put
on the fruit plate on the
transparent cover and then locate the
juice cup (with foam filtering plate
inside) under the juice out-let (make
sure the cup in correct direction, the
side with concave surface should be
towards the main unit).

Connect the power and turn the
control button to ″1″, then the unit
starts to work.

Put the cut fruit or vegetable in the
plate and push them into the guide hole
with the fruit / vegetable. Press and
make sure the volume is not more
than1/3of the guide hole and press
them slightly.

Please get rid of the residue in the
separating trough after extracting every
500g fruit or vegetable.

Note: Do not put your finger or other
things into the guide hole. Otherwise it
will be dangerous.
Safety protection
The motor is equipped with protective
setting, which will turn off the unit
automatically while overloading and re-
operate it after cooling.
Electric circuit diagram
Troubleshooting
Trouble
Possible
reason
Cause
check
Motor
does not
operate
Safety lock
is not
connected
Reassemble
the cup and
connect with
the base
correctly.
Motor
overheats
or smells
not good
Too much
food or
working
time to
long
Reduce the
food and run
it again after
the unit cool
down
Maintenance
1. Avoid any bumping of the appliance,
otherwise it will be deformed or broken.
2. After usage, please clean the
appliance and wipe the parts with a dry
cloth and store it in dry and windy
place.
Specification
Power: 300 W
Rated voltage: 220–230 V
Rated frequency: 50 Hz
Rated current: 1.4 A
Set
JUICER 1
INSTRUCTION MANUAL
WITH WARRANTY CARD 1
PACKAGE 1
ENVIRONMENT FRIENDLY
DISPOSAL
You can help protect the
environment!
Please remember to respect
the local regulations: hand in
the non-working electrical
equipment to an appropriate
waste disposal center.
The manufacturer reserves the right
to change the specification and
design of goods.
