4
The appliance is equipped with a safety
system. It won't work if the parts have not
been mounted properly.
1 Remove all packaging materials, take care
not to damage any components. Remove
the food pusher from the transparent cover.
2 Pull the safety locking arm downwards.
3 Lift and remove the transparent cover.
4 Lift away the filter basket by holding the
rim of the filter. Remove the integrated pulp
container.
WARNING!
Take care when handing the filter basket,
as the blades on its surface are very sharp.
Make sure the juicer is switched off.
Wash the transparent cover, food pusher,
filter basket, integrated pulp container and
juice jug in warm, soapy water to remove
any manufacturing residue.
Using Your Whole Fruit Juicier
ASSEMBLY
1 Place the main unit on a flat, dry surface
such as a bench top.
2 Make sure the plug of the main unit is
unplugged, and the switch is in the gear of
"0".
3 Place the integrated pulp container on top
of the main unit. Locate the integrated pulp
container so that the spout fits through the
hole in the front of the main unit.
4 Align the arrows of the stainless steel
filter basket with the arrows of the motor
drive coupling and push down until it clicks
into place. Ensure the stainless steel filter
basket is fitted securely inside the integrat-
ed pulp container and onto the main unit.
5 Place the transparent cover over the
stainless steel filter and integrated pulp
container. The humps of the rim of the
transparent cover should align with the
small plastic wings on the integrated pulp
container. Lower into position .
NOTE:
The transparent cover can be positioned in
either of the plastic wings on the integrated
pulp container.
6 Raise the safety locking arm up and lock
into the two grooves on either side of the
transparent cover. The safety locking arm
should now be in a vertical position and
locked into place on top of the transparent
cover.
NOTE:
The juicer will not operate unless the safety
locking arm is latched onto the transparent
cover.
7. Place the juice jug provided, sideways
under the spout of the juicer. Note the juice
jug need to be placed under the juice spout
rightly, and cover the lid.
NOTE:
A glass could also be used to collect the
juice, but using the jug and lid is recom-
mended to avoid any splatter. Your juicer is
now ready for use.
Food preparation
5
1. The best result will be obtained if your
juice really fresh produce, as foods which
have been stored for any period of time will
be dried out.
As a general guideline, you do not need to
peel any fruits and vegetables whose skin
you would normally eat. However, we do
recommend washing all foods before it is
juiced, as the majority of commercially
grown fruits and vegetables are sprayed
with fertilizers and insecticides.
2. Always trim off any blemishes.
3. Scrub carrots etc. with a brush to re-
move any dirt.
4. Remove skin from thick skinned fruits,
such as melon and pineapple.
5. Remove stones from cherries, peaches,
nectarines etc.
6. Leafy herbs and vegetables should be
rolled tightly.
Juicing
Food preparation
NOTE:
Ensure that a container is placed under the
juice outlet to collect the juice.
1 .Assemble the machine correctly, turn the
switch to gear "0" and insert the plug into
the right electrical outlet.
2. Place the main unit onto a flat stable
surface.
Note:
Make sure the main unit can not be placed
on the surface, which with water juice or
other liquid. In case during the operation,
the liquid gets into the main unit, affect
using.
3. Wash the fruits and/or vegetables and
cut them into pieces that fit into feed tube.
4. Turn the switch to suitable gear.
Switch on.
1 gear: suitable for soft fruits and vegeta-
bles, such as watermelon, grape, tomato,
cucumber, strawberry.
2 gear: suitable for all fruits and vegeta-
bles.
5. Put the fruits or vegetable into the feed
tube .
6. Use the food pusher to gently press the
food against the filter. If you push too hard,
less juice will be extracted and you risk
damaging your juicer.
NOTICE:
Never insert your fingers or any objects into
the feed tube.
Do not operate the juicer for more than two
minutes at one time when juicing heavy
loads and let it cool down for 2 minutes
before reuse.
7. After the juice flow has stopped, switch
the appliance off and wait until the filter has
slopped rotating.
When juicing very soft fruits, such as
strawberries, peaches etc., you
may find that they are juiced as soon as
they reach the filter.
When you juice your fruits and vegetables,
the pulp will accumulate in
the integrated pulp container.
Always empty the container before it gets
too full. If you are juicing apples (for exam-
ple), the pulp can be used to make apple
cake recipes.
