Saturn ST-FP0069 - Инструкция (Страница 5)

8
Safety
l Never fit the blade unit to your
machine without the jar fitted.
l Don’t touch the sharp blades. Keep
the blade unit away from children.
l Never remove the mill until the
blades have completely stopped.
Important
l To ensure long life of your
mill/coffee grinder, never run for
longer than 30-60 seconds. Switch
off as soon as you’ve got the right
consistency.
l The machine won’t work if the
mill/coffee grinder is fitted incor-
rectly.
l Use for dry ingredients only.
To use your mill
1 Put your ingredients into the jar. Fill
it no more than half full.
2 Fit the sealing ring into the blade
unit.
3 Turn the blade unit upside down.
Lower it into the jar, blades down.
4 Screw the blade unit onto the jar
until it is finger tight.
5 Place the mill onto the power unit
and turn to lock (j).
6 Switch on to maximum speed or
use the pulse control.
7 After milling, you can replace the
blade unit with the sprinkler lid
and shake out your food.
Hints
Herbs are best milled when clean and
dry.
Juicer
Put the Bowl like this way, make sure
the mark and the main body mark is on
the same way. Then you can turn the
bowl clockwise, after you heard a сlick,
and the bowl is on the way as per the
right photo ,the machine is assembled
correctly.
When finished the working, you can turn
the bowl out by anti-clockwise turning.
Never insert your hand or another ob-
ject (e.g. a fork, knife, spoon or spatu-
la) into the feeding tube. Only use the
pusher supplied with the appliance for
this purpose. Wait until the sieve has
completely stopped rotating before you
remove the lid.
- Always check the sieve before use. Do
not use the juicer if you notice any
damage like cracks, crazes or a loose
grating disc.
- The standard processing time for all
juicing jobs is 30-120 seconds.
- Peel citrus fruits, pineapples, melons,
etc. before you juice them.
- Stone cherries, plums, apricots,
peaches, etc. before you juice them.
To use your whisk
You can use the balloon beater to whip
cream, to whisk eggs and egg whites
and to make instant pudding, mayon-
naise and sponge cake mixture. Do not
use the balloon beater to prepare cake
mixtures with butter or margarine or to
knead dough. Use the kneading acces-
sory for these jobs.
Do not fill the bowl beyond the MAX
indication.
- Make sure the bowl and the balloon
beater are dry and free from grease
when you whisk egg whites. The egg
9
whites have to be at room temperature.
- Always clean the balloon beater after
use.
Care and cleaning
1 Always switch off and unplug before
cleaning.
2 Handle the blades and cutting discs
with care – they are extremely
sharp.
3 Some food may discolor the plastic.
This is perfectly normal and won’t
harm the plastic or affect the flavor
of your food. Rub with a cloth
dipped in vegetable oil to remove
the discoloration.
Power unit
Wipe with a damp cloth, then dry. En-
sure that the interlock area is clear of
food debris.
Liquidiser/mill
1 Empty the jug/jar before unscrew-
ing it from the blade unit.
2 Wash the jug/jar by hand.
3 Remove and wash the seals.
4 Don’t touch the sharp blades, brush
them clean using hot soapy water,
then rinse thoroughly under the
tap. Don’t immerse the blade unit
in water.
5 Leave to dry upside down.
All other parts
l Wash by hand, then dry.
l Alternatively they can be washed
on the top rack of your dishwasher.
A short low temperature program
is recommended.
Customer care
If the cord is damaged, it must be
replaced by the manufacturer service
agent in order to avoid a hazard.
Technical Data:
Power: 1000 W
Rated Voltage: 220-240 V
Rated Frequency: 50 Hz
Rated Current: 5 А
Set
Chopper 1
Juicer 1
Blender 1
Citrus juicer 1
Mill/coffee grinder 1
Whisk 1
Slicing/ shredding disc 1
French potato disc 1
Potato mashing disc 1
Spatula 1
Instruction Manual
with Warranty Book 1
Package 1
ENVIRONMENT FRIENDLY
DISPOSAL
You can help protect
the environment!
Please remember to re-
spect the local regulations:
hand in the non-working
electrical equipments to an
appropriate waste disposal
center.
The manufacturer reserves the right
to change the specification and de-
sign of goods.
RU
КУХОННЫЙ КОМБАЙН
Уважаемый покупатель!
Поздравляем Вас с приобретением
изделия торговой марки “Saturn”.
Мы уверены, что наши изделия
будут верными и надежными по-
мощниками в Вашем домашнем
хозяйстве.
Не подвергайте устройство резким
перепадам температур. Резкая
смена температуры (например,
внесение устройства с мороза в
теплое помещение) может вы-
звать конденсацию влаги внутри
устройства и нарушить его работо-
способность при включении.
Устройство должно отстояться в
теплом помещении не менее 1,5
часов. Ввод устройства в эксплуа-
тацию после транспортировки
производить не ранее, чем через
1,5 часа после внесения его в по-
мещение.
Перед эксплуатацией устройства
· Внимательно ознакомьтесь с
данной инструкцией по экс-
плуатации и сохраните её на
будущее
