(Ritmix
^ moving sound
RPR-I380
Instruction Manual
FM/AM/SW1-10 Digital Radio with Clock and Alarm
® @
- ®
-©
1.
Display
12.
FM Indicator
2.
Band switch
13.
AM band Button
3.
Tuner
14.
AM Indicator
4.
Hour adjustment button
15.
Time set button
5.
Earphone jack
16.
Time turn on set button
6.
Tone switch
17.
Time Switch button
7.
Volume control
18.
Minute adjustment button
8.
Power turn off button
19.
Telescopic Antenna
9.
Power turn on button
20.
Hand belt
10.
Power Indicator
21.
220Vpower socket
11.
FM band Button
22.
Battery slot
4.
Press
the
AM
band
button
(13),
to
receive
AM
program
and
move
the
Band
switch
(2)
to
select
AM, SW1-10 station program meanwhile the AM indicator (14) will light up.
5.
Turn the Tuner (3) and watch the station frequency on LCD, search your desired station program.
6.
The
tone
switch
is
set
In
the
radio,
you
can
select
different
tone
when
receiving
program.
Move
the
tone
switch
to
the
position
HIGH
when
receiving
news
program,
move
the
tone
switch
to
the
position LOW when receiving music program.
7.
In order not to affect others, you can use earphone to listen to the radio. Plug the earphone In
the Earphone jack (5) (the speaker Inside the radio Is deactivated), you can appreciate HI-FI
station program.
8.
When you do not want to listen to the radio, press the Power turn off button (8) to turn of the
power.
CLOCK SETTiNG
1.
After Installing batteries. In the state of clock the “12:00” appears on LCD.
2.
Keep the Time set button (11) pressed meanwhile press the Hour adjustment button (12) to
adjust hour, press the Minute adjustment button (16) to adjust minute, set the clock time.
3.
If you want to see the time In the state of work set the power switch to position OFF the time
appears on the display screen.
4.
The
12
hours
system
Is
used
In
the
radio.
The
AM
on
the
display
screen
Indicates
morning
time,
PM Indicates afternoon time.
TiME SETTING
After you complete to set the electronic clock time correctly, you can set the timing turn on time:
1.
In the state of clock, press the Time turn on button (16) pressed, the symbol of “ ^ ” and
morning
fime appears on the display screen. Press the Hour adjustment button (4) to adjust hour and
press the Minute adjustment button (18) to adjust minute. Adjust to your desired time to turn on
the radio.
2.
When
the
radio
works,
press
the
Timing
turn
on
button.
The
Timing
turn
on
time
displays
on
the
display screen and the symbol of
Attention: When setting time turn-on time, AM means morning time, PM means afternoon time.
TiMiNG FUNCTiON
1.
After the timing turn on time Is set, keep the radio In the state of clock.
2.
Press the Time switch button (17) once the symbol of " ^" displays on the display screen, the
timing
turn on function begins to work. When the turn on time reaches, the radio will automate to be
turned on, the FM band frequency will display on the display screen.
3.
Use the time turn on function to turn on the radio, the Power turn off button (8) doesn’t function.
Press the Time switch button (17) to cancel the symbol of " ^" then you can turn off the radio.
LCD EXPLANATiON
USE ANTENNA
1.
FM and SW frequency unit Indication
2.
AM frequency unit Indication
3.
FM or time Indication
4.
Time turn on function Indication
5.
Time turn on set and time Indication
6.
PM time Indication
7.
AM band or AM time Indication
8.
FM band Indication
PRECAUTIONS
1.
Avoid fierce lash, falling Into the ground.
2.
Do not put the radio In the place under sunshine, hot or humid.
3.
Keep magnetic tape, magnetic card and other magnetic record software away from the speaker.
In order to avoid that the record Is erased or there Is noise In the magnetic tape.
4.
Do not use new and old batteries together. When the volume gets faint or there Is distortion,
please change the batteries In time.
5.
When you do not use the radio for a long time, please take out the batteries lest the leakage of
the batteries corrodes the parts In the radio.
6.
Each Index of the radio Is adjusted well, so please do not adjust the components In the radio.
CLEANiNG THE CABINET
Use a soft cloth with detergent to clean the cabinet. Please do not use alcohol, thinner and other
strong detergent to clean It.
POWER
Installing batteries
1.
The radio uses three UM1 batteries, please put the new batteries In the battery slot according to
the polarity.
2.
If the sound Is with distortion or the volume Is faint, please change the batteries In time.
Attention:
1.
Do not use new and old or different type batteries together
2.
In order to prevent the leakage of the electrolysis liquid or danger of explosion, do not charge,
heat or resolve the batteries.
3.
If you do not use the radio for a long time, please take out the batteries, lest the leakage of the
battery corrodes the parts of the radio.
220V External Power
When
using
external
power
connecting
the
radio
with
220V
outlet
by
220V
external
power
line,
the
battery supply Inside the radio Is cut automatically.
Attention:
The
mains
voltage
for
the
radio
Is
180V-220V,
If
the
voltage
exceeds
the
range,
the
radio
will
work
abnormally.
1.
Receiving AM by using the Internal magnetic antenna, and you can get the best reception by
rotating the direction of the radio.
2.
When you receive FM station, please pull out the Telescopic Antenna to get the best reception by
changing the length and angle.
3.
When you receive SW station, please pull out the Telescopic Antenna and keep It vertical to get
the better reception.
COMMON PROBLEMS & HANDLE
1.
The AM and SW are strongly jammed by the TV set, fluorescent lamp, silicon controlled table
lamp, computer and motor and so on. When you use the radio, please keep the radio away from
the above mentioned equipment.
2.
Reinforcing bar structure Inside the multl-stored building and high building will screen the
broadcast signal; receiving near the window will Improve reception effect.
3.
The SW and FM broadcast will be strongly jammed by the nearby “BB” station signal; you can
Improve reception effect by adjusting the length of the antenna and the angle of the radio.
4.
You can use the soft antenna, one end Is stuck to the antenna, the other end Is put outside the
window. It will Improve SW and FM receiving effect.
5.
The
digit
display
radio
Is
affected
by
the
temperature,
humidity
and
vibration
and
so
on,
the
digit
frequency
will
deviate.
So
In
using
time
turn
function
If
the
frequency
deviates,
please
adjust
the
correct station.
6.
When the temperature Is under -IOC In winter. It will cause the leakage of LCD In general. Please
avoid using the radio under low temperature.
TECHNICAL INDEX
Frequency Range;
FM
64-108
MHz
AM
526.5-1606.5
KHz
SW1
3.90-4.30
MHz
SW2
4.75-5.06
MHz
SW3
5.95-6.20
MHz
SW4
7.10-7.30
MHz
SW5
9.50-9.90
MHz
SW6
11.65-12.05
MHz
SW7
13.60-13.80
MHz
SW8
15.10-15.60
MHz
SW9
17.50-17.90
MHz
SW10 21.45-21.85 MHz
Sensitivity;
FM £ 20mV
AM £ 3mV/m
SW£l00mV
AM S/N;
¿lOdB
Power;
AC 220V 50 Hz
DC 4.5V
3 UM 1 batteries
Speaker;
102mm/8n/3W
Earphone;
3,5mm 32 n
Size;
225x123x54 mm
Weight;
642gram (without battery)
OPEARTION
1.
Press the Power turn on button (9) to connect the radio power, the Power Indicator (10) lights up.
2.
Turn the Volume control (7) to adjust to the optimum volume.
3.
Press the FM band button (11) to receive FM program, meanwhile the FM Indicator (12) will light up.
