ENGLISH
3.TECHNICAL DATA
Fig. 2 (panel)
Air flow, m^/h
200
Power supply, V/Hz
220/50
Power consumption, W
45
Rated current, A
0,2
Water protection
IPXO
Electrical protection class
II
Device dimension, mm
420x158x390
Net weight kg
4,0
5
6
7
8
4. PRODUCT DESCRIPTION
Fig. 1 (front panel)
1 - Air outlet grille (air processed)
2 - Control Panel
3 - Castle of air inlet grille filter
4 - Air inlet grille filters
Fig. 1
5 - Power on-off Ionizer
^
6 - Button low fan speed (minimum power)
7 - Button average fan speed (average power)
8 - Button high fan speed (maximum capacity)
9 - Power on-off device
COMPLETE SET
1. Air Purifier -1 pc.
2. Instruction Manual -1 pc.
3. Warranty Card -1 pc.
4. Packing -1 pc.
5. OPERATION OFTHE INSTRUMENT
Before switching on the device, open the compartment for the filters,
remove the filters, remove them from plastic bags and put in place in the
same manner.
Connect the equipment into an outlet. Click on-off unit, air cleaner will work.
Press the button again, the device turns off.
Air ionisation (ION)
Clicking the button (5), you can turn on and off air ionizer.
The choice of power level
Air has three modes of power to switch, use the buttons for fan speed;
button (6) - Low fan speed (minimum capacity of the device), button (7)-the
average fan speed (average power) button (8) - high fan speed (the
maximum capacity of the device).
