ENGLISH
6. Operation of the unit
To disconnect the unit again, press Power (On/Off).
The choice of operating modes
To select one of four modes of operation, press the 6 button (selection
mode). Above the button will illuminate the appropriate indicator.
In eco-mode operation (indicator Econom) performance on humidifying
device will be 180 ml/h (fan speed 1100 RpM, power 32 W). In this mode,
the tank will be spent over 22 hours. The noise level will not exceed 30
dB (A).
In comfort mode (indicator Comfort) on the instrument performance
hydration of 320 ml/h (fan speed 1100 RPM, power consumption 200
watts). In this mode, the tank is used up in 12 hours. The noise level will
not exceed 30 dB (A). In this mode, for better performance on
humidifying device uses hot air.
In intensive mode (LED Turbo) performance on humidifying device is
500 ml/h (fan speed 1600 rpm, power 380 W). In this mode, the tank will
be spent over 8 hours. The noise level will not exceed 40 dB (A). In this
mode, for better performance on humidifying device uses hot air.
In automatic mode (the LED Auto) performance on humidifying device is
automatically adjusted.
If the humidity is 50-60% and above, includes economical mode
Econom.
If the humidity level of 40-50%, included a comfortable mode of
Comfort.
If the humidity is 40% or less, included intensive mode Turbo.
Indication of level of relative humidity
In the process of the device in the display area is displayed through the
plastic of the current level of relative humidity in the room (figure).
The optimum relative humidity for a man of 40-60%.
In addition, the device is equipped with a color indicator of moisture.
The vertical luminescent band in the center of the device changes color
depending on the level of relative humidity.
white LED indicates that the air is dry enough (40% and below).
Blue indicator light shows that air in the room good, moist (40-60%).
Green light indicates that the air is excessively humid (60% and above).
Blocking panel
To protect user-selected settings control panel can be locked. To do this
within 3 seconds to hold the lock button 8.
Timer to shut down
By clicking on the timer, you can choose the time after which the device
will automatically shut off:
"O" - Shut off after 2 hours,
"3 " - Off after 4 hours
"3" - Off in 6 hours
"3 " - Shut off after 8 hours.
7. Cleaning and maintenance of the unit
Prior to cleaning make sure that the plug is disconnected from an outlet.
Otherwise it may result in an electric shock.
Before cleaning, wait until water in grooves is completely cooled down in
order not to burn hands.
7.1 T o wipe the external surface of the unit use a damp and soft cloth.
T o prevent an electric shock do not scratch and do not damage unit's
elements upon cleaning.
When cleaning the unit, do not use solvents, benzine, dimethylbenzene, hard
brush, talc powder and other substances other than water.
7.2
Wipe water remains inside the groove under the tank by a damp and soft
cloth.k.
T o remove water remains on small parts you can use the brush, and then wipe
them again with a soft cloth. Clean the unit once or twice a wee
8. Troubleshooting
In case of emergencies resort to troubleshooting methods, given in tables.
If you are unable to solve issues by means of mentioned methods, contact
a service center.Life of the humidifier is 5 years.
Upon expiration of the humidifier it must be disposed in accordance with
regulations, rules and by means, currently in force at a disposal station.
www.timberk.ru • ultrasonic humidifier 5
Scheme of extraction pallet for water and water tank
roller for humidifying
and purification
Compartment
cover for water tank
pallet for water
Periodically clean the pallet and roll.
water tank cover
C
attention !
Order to get the pallet, you must first remove the water tank.
Panel control 1 2 3 4 5
5
Fig. 2
8 7 6
1 - The indicator of lack of water
2 - Lock Indicator panel
3 - Timer indicators (from left to right): device off after 2h, 4h, 6h, 8h
4 - Indicators of modes (from left to right): economic (Econom), intensive
(Turbo), automatic Auto, comfortable Comfort
5 - Power on / off Power (On / Off)
6 - Push button operation modes: Economy (Econom), intense (Turbo),
automatic (Auto), comfort (Comfort)
7 - Button timer for automatic shut-off device after 2h, 4h, 6h, 8h
8 - On / Off button lock control panel
scope of delivery
1. Air washer - 1 pc.
2. Operation manual - 1 pc.
3. Guarantee card - 1 pc.
4. Packing - 1 pc.
5. Filling tank with water
Prior to filling the tank remove the cover from the tank.
1. Grab the tank handle and pull it upwards.
2. Unscrew the tank cap counterclockwise.
3. Fill the tank with water.
4. Screw the tank cap clockwise.
Make sure the tank cap is securely tightened. Be sure that the rubber
gasket is installed to the tank cap.
5. Install watertank inside the device.
O Important!
1. T o prevent an electric shock, prior to dismantling the device
(removing the tank), unplug the device from electric mains! 2. D o
not fill the tank with liquids other than tap water.
Other composition of liquids has an adverse effect on internal
parts and results in a failure.
3. D o not fill the device or the water tank with such additives as
essential oil, flavoring substance, detergent, chemical medical
products, warm water (over 40°), etc.
Otherwise the water tank and internal parts of the unit will be
damaged and be broken.
4. D
o not fill water directly into the internal part of the unit or the
atomizer.
Water inside the unit may result in failure of the device.
5. D
o not hit and do not throw the water tank. It can be damaged
which will result in water leakage. D o not use the unit in case the
tank is heavily hit.
Contact a maintenance service or maintenance and repair station
immediately.
6. Every day fill the tank with pure water and keep the unit clean.
www.timberk.ru • ultrasonic humidifier 4
