11
*1 When the unit is turned off.
*2 When the unit is turned on.
*3 When the audio output is set to “SUB.”
Using optional equipment
CD/MD changer
Selecting the changer
1 Press (SOURCE) repeatedly until “CD” or
“MD” appears.
2 Press (MODE) repeatedly until the desired
changer appears.
Playback starts.
Skipping groups and discs
1 During playback, press (GP/PRESET)
+/–.
Repeat and shuffle play
1 During playback, press (3) (REP) or (4)
(SHUF) repeatedly until the desired setting
appears.
*1 When one or more CD/MD changers are connected.
*2 When one or more CD changers, or two or more
MD changers are connected.
To return to normal play mode, select “REP-
OFF” or “SHUF-OFF.”
Tip
“SHUF-ALL” will not shuffle tracks between CD units
and MD changers.
Locating a disc by name — list-up
You can select a disc from the list when
connecting a CD changer with the CUSTOM
FILE function or an MD changer.
If you assign a name to a disc, the name appears
on the list. For details on labelling a disc, see
page 10.
1 During playback, press (LIST).
The disc number or disc name appears.
2 Press (LIST) repeatedly until the desired disc
appears.
After 5 seconds, the unit returns to normal
play mode.
3 Press (SEEK) –/+ to play the disc.
With the card remote commander
In step 2, to select the disc, press
M or m.
Rotary commander RM-X4S
Attaching the label
Attach the indication label depending on how
you mount the rotary commander.
M.DSPL* 2
(Motion
Display)
To select the Motion Display
mode.
– “SA” (
z
): to show moving
patterns and spectrum
analyzer.
– “ON”: to show moving
patterns.
– “OFF”: to deactivate the
Motion Display.
CONTRAST To adjust the contrast of the
display.
The contrast level is adjustable
in 7 steps.
A.SCRL
(Auto Scroll) To scroll long displayed items
automatically when the disc/
group/track is changed.
– “ON”: to scroll.
– “OFF” (
z
): to not scroll.
LPF* 3 (Low
Pass Filter)
To select the cut-off frequency
“78HZ,” “125HZ” or “OFF”
(
z
).
To skip Press (GP/PRESET)
group and release (hold for a
moment).
group
continuously within 2 seconds of first
releasing.
discs repeatedly.
Disc number Unit number
To skip Press (GP/PRESET)
discs
continuously then, press again within 2
seconds and hold.
Select To play
REP-DISC* 1 disc repeatedly.
SHUF-
CHGR*
1
tracks in the changer in random
order.
SHUF-ALL* 2 tracks in all units in random
order.
continue to next page t
SEL
DSPL
MODE
SEL
DSPL
MODE
