LOCATION OF THE BUTTONS
;
T TP/PTY (traffic programme/programme
type) button
a
TAPE CD-CH (CD changer) button
s
∞
(down) button
Display window
d
LOUD (loudness) indicator
f
EQ (equalizer) indicator
g
(tape-in) indicator
h
TAPE indicator
j
CD-CH (CD changer) indicator
k
FM band indicators—FM1, FM2, FM3
l
AM band indicator
/
Tuner reception indicators—MO (monaural),
ST (stereo)
z
RDS indicators—AF, REG, TP, PTY
x
Volume (or audio) level indicator
c
MP3 indicator
• Lights up only when playing an MP3 disc on
a JVC MP3-compatible CD changer.
v
(disc) indicator
• Lights up only when connecting to a CD changer.
b
Main display
n
RND (random) indicator
• Lights up only when connecting to a CD changer.
m
RPT (repeat) indicator
Control panel
1
Remote sensor
2
Control dial
3
(standby/on/attenuator) button
4
SEL (select) button
5
Screws—M2
×
5 mm (only for KS-T807)
6
Plate cover and standard plate
(only for KS-T807)
7
FM/AM DAB button
8
5
(up) button
23
(tape direction) button
9
0
(eject) button
p
4
/
¢
buttons
q
(control panel release) button
w
DISP (display) button
• Also functions as SSM buttons when pressed
together with M MODE button.
e
M MODE button
• Also functions as SSM buttons when pressed
together with DISP (display) button.
r
Display window
t
EQ (equalizer) button
y
MO (monaural) button
u
RPT (repeat) button
i
RND (random) button
• Functions only when connecting to a CD changer.
o
Number buttons
s
a
;
t
r
e
w
q
y
u
i
o
1 2 3 4
78 9
p
6
d
f g
h
j
k
l
/
z
x c
v
m
n
b
5
Display window
