1
mum ^mm^mm/mm^.xmi)
[VIDEO OUT I VIDEO IN(g;it)
[AUDIO OUi| ‘AUDIO IN(-i-T5}
3 l^lVCR CAMERA|ifi,Sii[VCR|iim
• [VCRlig^iSO^^
4 (->56)
• 5п^a¡^^míTwт^^1íSB‘m/mmrnXt^im.
ISRF||i#t|(VW-RF7L. iimmft),
Playing Back on a TV
By connecting the Movie Camera to a TV, you can
watch playback of the recorded scenes on the TV
screen.
Before connecting, turn off both the Movie Camera and
the TV for safety's sake.
1
Use the AV Cable (supplied) to connect
the Movie Camera with theTV.
Movie Camera TV (AV Input Sockets)
[VIDEO OUT] > VIDEO IN
[AUDIO OUT] --------------> AUDIO IN
2
Select the channel on theTV which
corresponds to the video/audio input
sockets used for connecting.
(Refer to the operating instructions of your TV).
3
Press the [VCR/CAMERA] Button to
select the VCR Mode.
•The [VCR] Lamp O lights.
4
start playback on the Movie Camera.
(-►56)
If your TV is not equipped with AV Input Sockets, the RF
Adaptor (VW-RF7E; optional) is necessary.
Consult your dealer.
58
