On the control panel, are the following symbols:
Position tap closed
Large flame maximum opening/delivery
Small flame minimum opening/reduced delivery
• To light one of the burners, press and turn the
relevant knob anticlockwise to the large flame
position and keep the knob pressed until the burner
ignites. If the burner does not ignite repeat the
operation.
• If the flame extinguishes, turn the knob to
position
and do not try to light the burner for at
least 1 minute.
• For gas economy, use pots and pans according to
the gas burners size:
Burner type Pan diameter
Large (Rapid) 220 - 280 mm
Medium (Semi-rapid) 160 - 220 mm
Small (Auxiliary) 130 - 160 mm
Cover pans whenever is possible. Avoid using pans with a
misshapen base. Do not use rounded shaped pans, such as
WOK.
USING THE OVEN/GRILL
To operate the gas oven
1. Open the oven door.
2. Gently press the knob and turn to the left to the desired
cooking temperature.
3. To light the burner, offer a match to the hole in the
oven floor. Once the burner is lit, keep the knob pressed
for about 10 seconds.
4. Close the oven door.
5. Preheat the oven for about 15 minutes.
6. Open the oven door.
7. Place the food in the oven.
8. Close the oven door.
Important: If the burner fails to ignite within 10 seconds,
open the oven door and wait for 5 minutes before further
attempts.
To operate the gas grill
1. Turn the oven/grill control knob clockwise to
symbol .
2. Place the heat shield at the top section of the oven.
3. To light the grill offer a match to the grill burner
positioned in the upper part of the oven. Once the
burner is lit, keep the knob pressed for about
10 seconds.
4. Preheat the grill for about 5 minutes.
5. Place the food in the centre of the wire shelf.
6. Close the oven door until the heat shield is in contact
with the cooker front.
7. Turn the food half-way through cooking.
Attention: When grilling the oven door is hot: please
keep children away!
TABLE - Technical data
Gas setting G20
Gas pressure 1,3 kPa
Max power gas 9,5 kW
Supply voltage and power 230 V, 50 Hz, 21 W
USING THE BURNERS
3gb66038.fm Page 2 Monday, January 27, 2003 3:42 PM
5019 310 66038
• Откройте дверцу духовки.
• Установите опору вертела (1) на второй
уровень духовки. Поместите под него поддон.
• Наденьте продукт на вертел (4) и зажмите
его двумя вилками (3).
• Положите вертел с продуктом на опору.
• Вставьте вертел в отверстие привода в
центре задней стенки духовки.
• Снимите ручку (2) вертела на время готовки.
• Рекомендуется налить в поддон небольшое
количество воды, чтобы уменьшить
образование дыма и разбрызгивание жира.
• Установите отражатель под панелью
управления.
• Закрывайте дверцу духовки, пока она не
коснется отражателя.
• Включите вертел, нажав кнопку на панели
управления.
• Нагрейте гриль в течение 5 минут.
Блок вертела включает следующие компоненты:
опора вертела 1 шт.
ручка 1 шт.
вилки 2 шт.
вертел.
Внимание:
Во время работы духовка нагревается.
Не подпускайте к духовке маленьких детей.
ПОЛЬЗОВАНИЕ ВЕРТЕЛОМ
