PS3-1004 2-894-645-72(1)
4
Getting started
Part names
01
System front
CF SD/miniSD
Disc slot
CF* 1 slot* 3
SD* 2 Memory Card slot* 3
Memory Stick™ slot* 3
Slot cover* 3
Power button
Vent
USB connectors
HDD access indicator
WLAN access indicator* 3
PS family logo
Can be rotated to match the
position of the system
Eject button
Eject button* 3
* 1 CompactFlash
®
* 2 Secure Digital * 3 On equipped models only
Caution
• Do not use the system in a closed cabinet or other locations where heat
may build up. Doing so may cause the system to overheat and may lead to
fire, injury or malfunction.
• If the system's internal temperature becomes elevated, the power indicator
will flash alternately in red and green. In this case, turn off the system
( page 13) and leave it unused for a while. After the system cools down,
move it to a location with good ventilation, and then resume use.
System rear
AV MULTI OUT connector
DIGITAL OUT (OPTICAL) connector
HDMI OUT connector
MAIN POWER switch
AC IN connector
Vent
LAN connector
Notice
Do not place the system in an area subject to excessive
dust or cigarette smoke. Dust build-up or cigarette
smoke residue on the internal components (such as the
lens) may cause the system to malfunction.
Hint
The system can be set in a horizontal or vertical position.
Set as shown in the diagram at right when setting in the
vertical position.
