ENGLISH
6
button PROG/CLOCK
6. Button for choosing playback modes PLAY
MODE
7. Button for choosing media CD/SD/USB
8. Speakers
9. Remote control signals sensor REMOTE
SENSOR
20. LCD
2. USB-slot
22. Stereo signal LED FM STEREO
23. Slot for SD-card
2. Buttery compartment cover
2. Slot AUX In for connecting auxiliary device
26. Slot for connecting power cord
Remote control
27. Button for low frequencies amplification
BASS
28. Button for choosing operating mode MODE
29. Button for choosing playback mode PLAY
MODE
30. Playback programming/clock setting up
button PROG/CLK-ADJ
3. Playback stop button STOP ( ■)
32. Play/pause button PLAY/PAUSE ( ►║)
33. Button for skipping to the previous track/
setting up clock ( /CLK-ADJ)
3. Button for skipping to the next track / setting
up clock ( /CLK-ADJ)
3, 36. Buttons for switching between folders
FOLDER ( ▼)/(▲)
37, 38. Buttons for adjusting volume level
VOLUME ( ▼)/(▲)
Using Remote Control
Remote control is delivered with already in-
stalled butteries. Before using remote control
remove protecting plate out of it.
While using remote control direct it to infrared
sensor located on your player (REMOTE SEN-
SOR). If remote control stops working check out
the butteries and replace them if required.
. Extract buttery holder.
2. Turn buttery (СR 202) according to polarity
marks.
3. Insert buttery into compartment.
Do not expose remote control to high tempera-
tures and direct sun light, as it would affect per-
formance of the unit negatively.
Attention! In order to avoid buttery damage,
follow the next instructions:
- install butteries correctly,
- take the butteries out if you are not going to
use the unit for a long time;
- do not recharge butteries, disassemble
them or expose to high temperatures;
- replace butteries in proper time.
Power supply connection
Mains supply
Before connecting appliance to mains supply
source, make sure mains supply voltage meets
operating voltage of the unit.
. Connection to main supply line: insert
one power cord end in plughole (26) and
the other – into a wall outlet. Set switcher
FUNCTION into position CD or RADIO.
2. Switching appliance off: set switch
FUNCTION into position OFF/AUX.
Notice: Static electricity would interfere with
normal performance of the unit. In this case
disconnect the appliance from the power source
and then switch on again. If the problem still
appears, apply to the nearest authorized service
center.
Buttery power supply
. Disconnect the unit from the mains power
source.
2. Open buttery compartment cover located
at the back of the unit by pressing on two
latches along the arrow.
3. Insert eight butteries of «С» type (UM 2) ,
В (not included into delivery set) into the
buttery compartment.
. Close buttery compartment cover.
Attention! Buttery leakage would cause per-
sonal injuries or damage of the unit. Follow the
