Sharp SJ-F91SPSL - Инструкция (Страница 12)

12
When transporting
• Using the casters, it is possible to move back and forth.
• Carry the refrigerator by holding the handles located on the
rear and bottom.
Before using your refrigerator
Clean the inside parts with a cloth soaked in warm water.
If soapy water is used, wipe it off thoroughly with water.
1. Door pocket
2. Refrigerator shelf
3. Shelf
4. Bottle pocket (left)
5. Vegetable crisper
The cover of the Vegetable crisper
opens as the case is pulled.
6. Quick ice maker
The bottom of the tray contains refrigerant material
used in ice packs to speed up the ice making process.
The tray can also be used to freeze small food items
such as meat and fruits by removing the ice making
partition.
7. Freezer case (small)
8. Freezer case (large)
9. Casters
10. Adjustable feet
11. Foot cover
12. Aluminum panel
The panel is cooled from the rear, thus indirectly cool-
ing the refrigerator compartment. In this way, food is
refrigerated gently, without exposing it to cold air flow.
13. Refrigerator LED light
14. Plasmacluster light
15. Utility pocket cover
16. Utility pocket
17. Egg holder
18. Egg pocket
19. Bottle rack
20. Fruit case
21. Fresh case
22. Bottle pocket (right)
To store large-size bottles,
move the partition all the
way back.
23. Ice cube maker
• Do not over fill the tray;
otherwise the ice cubes will be
joined together when frozen.
• When the ice cubes are made, turn
the lever clockwise to empty the ice
into the Ice cube box.
24. Ice cube box
To prevent damage to the Ice cube
box, do not make ice in the Ice cube
box or pour oil into it.
25. Magnetic door seal
26. Control panel
Casters
rear bottom
DESCRIPTION
25
13 12 14 13
25
15
1
17
18
19
20
22
21
26
23
24
7
8
25
9
10
1
2
3
4
5
6
7
8
25
9
10
11
16
15
16
1
22
17
SJ-F96SP
SJ-F91SP
Partition
Lever
Ice cube box
