5. OPERATION GUIDE
5.1. Connect the satellite speakers to the proper socket on the rear panel of the subwoofer (color matched).
5.2. Connect the output signal of your computer or Audio player to the input plug of this unit.
5.3. When use microphone, please connect amplifier MIC input to computer sound card MIC input.
5.4. After connecting all the lead wires and make sure there is no mistake. Then plug the subwoofer power lead into the socket of power
supply AC220 V/50 Hz.
5.5. Turn the VOLcontrol (VOLUME) to the lowest level ,then switch on the power on the rear side of subwoofer (ON position).
5.6. Press «SELECT» button to start working (indicator light display).
5.7. Rotating the “TREBLE” to increase or decrease the satellite volume (Clockwise increase, Anti-clockwise decrease).
5.8. Rotating the “BASS” to increase or decrease the woofer volume. (Clockwise increase, Anti-clockwise decrease).
5.9. To switch a used input push quickly button SELECT.
5.10. When use Microphone and Earphone, Please insert Microphone and Earphone plug to proper faucet of separate amplifier, Then can
enjoy on the computer.
5.11. Turn the VOL to lowest level and cut off the power supply after playing.
5.12. Use the soundcard Line-Out port to improve sound quality.
Notes:
~ Please properly adjust the volume to reach the best music effect and carefully select the music signal source to ensure you have the best
music.
~ Distortion will be happened when you turn to the volume control to the maximum position.
~ The microphone connector in this unit has to work with a sound card in your computer or microphone amplifier.
~ Select left or right channel as you need when playing bilingual programmes.
