5. INSTALLATION AND OPERATION GUIDE
1.
Connect the sub-woofer and the front, center, surround speakers with link cables.
2.
Insert one end of the signal input cable into the output port of audio (video) player (DVD, CD/VCD, TV, APE), then connect another
end with input port at the back of the sub-woofer according to the red and the white cable respectively.
3.
Revolve all the function knobs to minimum volume then press the power button.
4.
Plug into power connector for power.
5.
Press button «BAND» to select signal sources, the indicator switch among «CD/ VCD, TV, TAPE, DVD the green indicator shows the
working channel.
6.
Press button «5.1/ST» to select the sound field mode. select «5.1», the six speakers are on playing despite AC-3 or SURR. input,
select «ST», only the front speakers and the subwoofer are on work.
7.
Press «AC-3 /SURR button to switch between AC-3 (6 chanels input) or SURR. (two channels input)
8.
Adjust the F.VOL knob for your satisfied front speaker volume effect.
9.
Adjust the S.VOL knob for your satisfied surround effect.
10.
Adjust the C.VOL knob for your ideal center effect.
Connection guide
12
OPERATION MANUAL
LOCATING
Center
Center
Subwoofer
Subwoofer
Right front
Right front
Left front
Left
surround
Right
surround
Left
surround
Right
surround
Left front
