UseR’s MAnUAL
12
5. DESCRIPTION OF THE REAL PANEL OF THE SUBWOOFER
AUX(l/R) To receive the signal from PC, CD, MP3, Tape
player,etc.
INPUT (5.1CH):
• Fl/FR: Front left/Right channel input connectors of the
system
• CEN: Center channel input connector
• SUB: Subwoofer channel input connector
• Sl/SR: Surround left/Right channel input connectors
of the system
OUTPUT (5.1CH):
• Fl/FR: Front left/Right channel output connectors
of the system
• Sl/SR: Surround left/Right channel output connectors
of the system
• CEN: Center channel output connectors.
AC IN: AC power cord
POWER ON/OFF: Switch for turn on/off the power
6. REMOTE CONTROL
POWER: Press «POWER» on/off of the speaker
RESET
MUTE: To indicate Mute on/off of the system
DVD: To switch the DVD mode
2.1/5.1: To indicate the output mode of the speaker system
AUX: To switch the AUX mode
CEN +/-: To increase/decress the volume level of the centre
speaker.
SW+/-: To increase/decrese the volume level
of the subwoofer speaker
REAR+/-: To increase/decrese the volume level
of the surround speaker
TREBlE+/-: To increase/decrese the tune of treble
of the subwoofer speaker
BASS+/-: To increase/decrese the tune of bass
of the subwoofer speaker
MASTER +(VOl+)/MASTER-(VOl-): To increase/decrease
the master volume of the speaker system
lEFT BAlANCE+/RIGHT BAlANCE+: To adjuste the volume
level of OF the front speaker
