5.1 Channel Home Theater System SS AAR 2550 SI
8 9
Instruction manual Eng
GENERAL SAFETY
INSTRUCTIONS
>
TECHNICAL
CHARACTERISTICS
Warnings!
>
Power Supply 230 V/50 Hz
Frequency Response 50 Hz – 18 кHz
Amplifier Output 5х10 W + 35 W (4 Om)
Dimensions (W х D х H) 300 х 415 х 410 mm
Weight 11 kg
The manufacture declines all responsibility for any damage caused
by improper, incorrect and unreasonable use of the appliance.
 Install this unit in a cool, dry, clean place, away from windows,
heat sources,sources of excessive vibration, dust, moisture and
cold Avoid sources of humming(transformers/motors). To preven
fire or electrical shock,do not expose the unit to rain or water.
 Never open the cabinet. If something drops into the set, contact
your Dealer.
 Do not attempt to clean the unit with chemical solvents; this might
damage the finish. Use a clean,dry cloth.
 When planning not to use this unit for long periods of time (i.e.,
Vacation, etc.), Disconnect the AC power plug from the wall out-
let.
 To prevent lightning damage,disconnect the AC power plug when
there is an electrical storm.
 Since this unit has a built-in power amplifier,heat will radiate from
the pear panel. Therefore, place the unit apart from the walls, al-
lowing a space of at least 10cm (3-15/16 “ ) above, behind and
on the both sides of the unit.
 Also, do not position with the rear panel facing down on the floor
or other surface.
Connection to DVD player
Turn off the audio source of VCD/CD/MP3
SURR. FRONT
AC ~230V 50Hz
POWER
AUX 5.1CH OUTPUT
L
R CEN
SUB
FL FR CEN SL SR
DVD
TV
+
