Connecting and operation guide
1. Insert the connecting plugs of satellite speaker into the subwoofer sockets as indicated on the rear panel L for the left channel R for the
right channel SL for the surround left SR for the surround right Ñ for the center.
2. Insert the surround sound channel signals (DVD+AC3) to the channel sockets L, R, SL, SR, C, SUB respectively.
3. After connecting all the lead wire sand make sure there is no mistake. Then plug the subwoofer power lead into the socket of power sup-
ply AC220/50 HZ.
4. Turn on the power switch on the rear side of the subwoofer.
5. Rotating the knob, VOLUME can increase or decrease.
6. Press «STANDBY» button to switch on the supply power.
7. Switch a used input press quickly «STANDBY” button.
8. More function can use the remote control to choose.
Eng SVEN SPS-870
13
Fig. 3. Connecting circuit
