6
English
Replacingthesystemouterfoilandtheinner
blades
appears on the LCD panel once a year. (This will differ
depending on usage.) We recommend checking the system outer
foil and the inner blades when it appears.
Press the OFF/ON switch for more than 30 seconds to delete .
system outer foil once every year
inner blade once every two years
Replacingthesystemouterfoil
1. Press the foil frame release
buttons and lift the outer foil
section upwards as illustrated.
. Press the system outer foil
release buttons and pull down
the system outer foil as
illustrated.
3. Align the foil frame mark
and the system outer foil
mark and securely attach
together.
The system outer foil cannot
be reversely attached.
Always insert the system
outer foil to the foil frame
when attaching to the shaver.
. After turning the mark to
the front, securely attach the
outer foil section to the shaver
until it clicks.
•
•
2 3
•

Replacingtheinnerblades
1. Press the foil frame release
buttons and lift the outer foil
section upwards as illustrated.
. Remove the inner blades one
at a time as illustrated.
Do not touch the edges
(metal parts) of the inner
blades to prevent injury to
your hand.
3. Insert the inner blades one at
a time until they click as
illustrated.
•
2 3
Cleaningwiththebrush
(A) (B)
1. Clean the inner blades using
the short brush by moving it in
direction (A).
Clean the system outer foil,
the shaver body and the
trimmer using the long brush.
Do not move the short brush
in direction (B) as it will
damage the inner blades and
affect their sharpness.
Do not use the short brush to
clean the outer foils. •
•

