32 GB
Specifications
Display Unit
Power Requirements:
220–240 V AC, 50 Hz
Screen Size:
KDL-40xxxxx: 40 inches
KDL-37xxxxx: 37 inches
KDL-32xxxxx: 32 inches
KDL-26xxxxx: 26 inches
Display Resolution:
1,366 dots (horizontal) × 768 lines (vertical)
Power Consumption:
KDL-40xxxxx: 165 W or less
KDL-37xxxxx: 150 W or less
KDL-32xxxxx: 130 W or less
KDL-26xxxxx: 90 W or less
Standby Power Consumption*:
KDL-40xxxxx: 0,6 W or less
KDL-37xxxxx: 0,6 W or less
KDL-32xxxxx: 0,7 W or less
KDL-26xxxxx: 0,7 W or less
* Specified standby power is reached after the TV
finishes necessary internal processes.
Dimensions (w × h × d):
KDL-40xxxxx:
Approx: 982 x 690 x 265 mm (with stand)
Approx: 982 x 643 x 124 mm (without stand)
KDL-37xxxxx:
Approx: 906 x 658 x 265 mm (with stand)
Approx: 906 x 611 x 126 mm (without stand)
KDL-32xxxxx:
Approx: 790 x 577 x 214 mm (with stand)
Approx: 790 x 530 x 119 mm (without stand)
KDL-26xxxxx:
Approx: 657 x 500 x 214 mm (with stand)
Approx: 657 x 453 x 121 mm (without stand)
Mass:
KDL-40P30xx/ KDL-40U30xx:
Approx: 23,5 kg (with stand)
Approx: 20,0 kg (without stand)
KDL-37P30xx/ KDL-37U30xx:
Approx: 21,0 kg (with stand)
Approx: 18,0 kg (without stand)
KDL-32P30xx/ KDL-32U30xx:
Approx: 15,0 kg (with stand)
Approx: 13,0 kg (without stand)
KDL-26P30xx/ KDL-26U30xx:
Approx: 12,0 kg (with stand)
Approx: 10,0 kg (without stand)
KDL-26Sxxxx/KDL-26Txxxx:
Approx: 12,5 kg (with stand)
Approx: 10,5 kg (without stand)
Panel System
LCD (Liquid Crystal Display) Panel
TV System
Depending on your country/region selection
Analogue:
B/G/H, D/K, L, I
Digital: DVB-T
Colour/Video System
Analogue: PAL, SECAM
NTSC 3.58, 4.43 (only Video In)
Digital: MPEG-2 MP@ML
Aerial
75 ohm external terminal for VHF/UHF
Channel Coverage
Analogue: 48.25 - 855.25 MHz
Digital: VHF Band III (177.5 - 226.5 MHz)
UHF E21 - E69 (474 - 858 MHz)
Terminals
/ 1
21-pin Scart connector (CENELEC standard) including
audio/video input, RGB input, and TV audio/video
output.
/ 2 (SMARTLINK)
21-pin Scart connector (CENELEC standard) including
audio/video input, RGB input, selectable audio/video
output, and SMARTLINK interface.
3
Supported formats: 1080i, 720p, 576p, 576i, 480p, 480i
Y: 1 Vp-p, 75 ohms, 0.3V negative sync
P
B /C B : 0.7 Vp-p, 75 ohms
P R /C R : 0.7 Vp-p, 75 ohms
3
Audio input (phono jacks)
500 mVrms
Impedance: 47 kilo ohms
HDMI IN 4, 5
Video: 1080i, 720p, 576p, 576i, 480p, 480i
Audio: Two channel linear PCM
32, 44.1 and 48 kHz, 16, 20 and 24 bits
PC (see table)
Analogue audio (phono jacks):
500 mVrms, Impedance 47 kilohms
(HDMI IN 4 only)
6 S video input (4-pin mini DIN)
6 Video input (phono jack)
6 Audio input (phono jacks)
Audio output (Left/Right) (phono jacks)
PC PC Input (15 Dsub) (see page 17)
G: 0.7 Vp-p, 75 ohms, non Sync on Green
B: 0.7 Vp-p, 75 ohms, non Sync on Green
R: 0.7 Vp-p, 75 ohms, non Sync on Green
HD: 1-5 Vp-p
VD: 1-5 Vp-p
PC audio input (minijack)
i Headphones jack
CAM (Conditional Access Module) slot
Additional Information
