17
GB
Using with External Devices
Continued
The Video Camera Settings dialog box appears.
z Hint
• If the “Background Download” box is checked, images can be loaded by
background processing. Refer to the on-line help for details.
• If the check mark in the “limit size of images in memory to 640
×
480” box is
turned on, the size of images that can be loaded back into the video camera will
be limited to VGA (640
×
480). If this box is not checked, the size of the image
that is loaded back into the camera will vary from camera to camera.
Note
Settings cannot be changed during connection with the video camera. To change
settings, Right click the Video Camera folder icon and select Disconnect from the
menu to momentarily cut the connection.
6
Make the desired settings, and click [OK].
Baud Rate:
The default rate is set at 115200 bps. A slower rate may be
used if serial communications problems occur.
Serial Port:
Select the PC port that corresponds to the connection in step
2. See the PC operating manual for the port number.
The settings are refreshed and the Video Camera Settings dialog box
closes.
