1-36
Left View
1
DC Jack A jack to connect the AC adapter that supplies power to the computer.
2
Wired LAN Port Connect the Ethernet cable to this port.
3
USB Port
(Optional)
You can connect USB devices to the USB port such as a keyboard/
mouse, digital camera, etc.
4
Monitor Port
A port used to connect a monitor, TV or projector supporting a 15pin
D-SUB interface.
5
Digital Video/Audio
Port (HDMI) (Optional)
You can connect an HDMI cable to this port. Using this port, you can
enjoy digital video and audio on the TV.
6
Microphone Jack A jack used to connect the microphone.
7
Headphone Jack A jack used to connect the headphones.
8
Multi Card Slot
(Optional)
A card slot that supports SD Card, SDHC, MMC cards and SDXC
cards.
1 2 3 4 5 6 7 8
