1-36
Left View
1 2 3 4 5 6 7 8
1
DC Jack A jack to connect the AC adapter that supplies power to the computer.
2
Wired LAN Port Connect the Ethernet cable to this port.
3 Fan Vents
The internal heat of the computer is emitted through these holes.
If the vents are blocked the computer may overheat.
Avoid blocking the vents as this may be dangerous.
4
Monitor Port
A port used to connect a monitor, TV or projector supporting a 15pin
D-SUB interface.
5
Digital Video/Audio
Port (HDMI) (Optional)
You can connect an HDMI cable to this port. Using this port, you can
enjoy digital video and audio on the TV.
6
USB Port
(Optional)
You can connect USB devices to the USB port such as a keyboard/
mouse, digital camera, etc.
7
Microphone Jack A jack used to connect the microphone.
8
Headphone Jack A jack used to connect the headphones.
