5 ASSEMBLING AND PREPARING
ENGLISH
Parts and buttons
y y The TV can be placed in standby mode in order to reduce the power consumption. And the TV
should be turned off if it will not be watched for some time, as this will reduce energy consumption.
y y The energy consumed during use can be significantly reduced if the level of brightness of the
picture is reduced, and this will reduce the overall running cost.
NOTE
y y Do not step on the glass stand or subject it to any impact. It may break, causing possible injury
from fragments of glass, or the TV may fall.
y y Do not drag the TV. The floor or the product may be damaged.
y y Some models have a thin film attached on to the screen and this must not be removed.
CAUTION
1 Antenna Isolator Installation Guide
y y Use this to install TV in a place where there is a voltage difference between GND of power and GND of antenna signal.
- If there is a voltage difference between GND of power and GND of antenna signal, the antenna contact might be
heated and excessive heat might cause an accident.
y y You can improve the safety when watching TV by efficiently removing power voltage from TV antenna. Avoid
disconnecting the antenna Isolator after installation.
y y Exterior of antenna isolator:
y y Connection method :
- Connect Plug 1 with a signal cable.
- Connect Plug 2 with ANT input end on the back of TV.
“Equipment connected to the protective earthing of the building installation through the mains connection or through other
equipment with a connection to protective earthing - and to a cable distribution system using coaxial cable, may in some
circumstances create a fire hazard.
Connection to a cable distribution system has therefore to be provided through a device providing electrical isolation below
a certain frequency range (galvanic isolator, see EN 60728-11)”
When applying the RF Isolator, a slight loss of signal sensitivity can occur.
ANTENNA
IN
ANTENNA
IN
RF Coaxial Wire
Isolator
or
ANTENNA
IN
ANTENNA
IN
ANTENNA IN
RF Coaxial Wire STB
Isolator
or
Isolator
or
Plug2
Plug1
Plug1 Plug2
