2

GB



Keep this instruction manual in a safe place for

future reference. Should the appliance be sold,

transferred or moved, make sure the instruction

manual accompanies the washing machine to inform

the new owner as to its operation and features.



Read these instructions carefully: they contain vital

information on installation, use and safety.

Unpacking and levelling

Unpacking

1. Unpack the washing machine.

2. Check whether the washing machine has been

damaged during transport. If this is the case, do not

install it and contact your retailer.

3. Remove the 3

protective screws and

the rubber washer with

the respective spacer,

situated on the rear of

the appliance (see

figure).

4. Seal the gaps using the plastic plugs provided.

5. Use the plug provided to seal the three holes

where the plug was housed, situated on the lower

right-hand side on the rear of your appliance.

6. Keep all the parts: you will need them again if the

washing machine needs to be moved to another

location.



Packaging materials are not children's toys.

Levelling

1. Install the washing machine on a flat sturdy floor,

without resting it up against walls, furniture cabinets

or other.

2. If the floor is not

perfectly level, compen-

sate for any unevenness

by tightening or

loosening the adjustable

front feet (see figure);

the angle of inclination,

measured according to

the worktop, must not

exceed 2°.

Levelling your appliance correctly will provide it with

stability and avoid any vibrations, noise and shifting

during operation. If it is placed on a fitted or loose

carpet, adjust the feet in such a way as to allow

enough room for ventilation beneath the washing

machine.

Electric and water connections

Connecting the water inlet hose

1. Insert seal A into the

end of the inlet hose

and screw the latter

onto a cold water tap

with a 3/4 gas threaded

mouth (see figure).

Before making the

connection, allow the

water to run freely until

it is perfectly clear.

2. Connect the other end

of the water inlet hose to

the washing machine,

screwing it onto the

appliance's cold water

inlet, situated on the top

right-hand side on the

rear of the appliance

(see figure).

3. Make sure there are no kinks or bends in the

hose.



The water pressure at the tap must be within the

values indicated in the Technical details table

(on the next page).



If the water inlet hose is not long enough, contact

a specialist store or an authorised serviceman.

Installation

A
