EN
15
Electrical connection
Before inserting the plug into the electrical socket, make
sure that:
• The socket is earthed and complies with current
regulations.
• The socket can withstand the maximum load of the
appliance, which is indicated on the data plate located
on the inside of the door (
see chapter entitled
Description of the appliance).
• The power supply voltage falls within the values
indicated on the data plate on the inside of the door.
• The socket is compatible with the plug of the appliance.
If this is not the case, ask an authorised technician to
replace the plug (
see Assistance); do not use extension
cables or multiple sockets.
Once the appliance has been installed, the power
supply cable and the electrical socket should be easily
accessible.
The cable should not be bent or compressed.
If the power supply cable is damaged, it must be re-
placed by the manufacturer or its Technical Assistance
Service in order to prevent all potential hazards. (See As-
sistance)
The Company shall not be held responsible for any
incidents that occur if these regulations are not observed.
Anti-condensation strip *
After installing the dishwasher, open the door and stick the
adhesive transparent strip under the wooden shelf in order
to protect it from any condensation which may form.
Advice regarding the first wash cycle
After the appliance has been installed, immediately before
running the first wash cycle, completely fill the salt
dispenser with water and add only then approximately 1 kg
of salt (
see chapter entitled Rinse aid and refined salt). The
water may overflow: this is normal and is not a cause for
concern. Select the water hardness value (
see chapter
entitled Rinse aid and refined salt). - After the salt has been
poured into the machine, the LOW SALT indicator light
*
switches off.
If the salt container is not filled, the water softener and
the heating element may be damaged as a result.
ECODESIGN REGULATION
ECO wash cycle is the standard cycle to which the energy label data refers; this cycle can be used to wash crockery with a normal soil
level and is the most efficient in terms of energy and water consumption for this type of crockery. To reduce consumption even further,
only run the dishwasher when it is full.
Standby consumption: Left-on mode consumption: 3 W – Off mode consumption: 1,3 W
Consumption data table for the main cycles
*
Cycle data refers to the values recorded in a laboratory, in accordance with European standard EN 50242.
**
Data is obtained by recording values when the appliance is operational and loaded with user crockery.
Standard conditions * User conditions **
Energy consumption
(kWh/cycle) Water consumption
(l/cycle) Duration
(min/cycle) Energy consumption
(kWh/cycle) Water consumption
(l/cycle) Duration
(min/cycle)
INTENSIVE 1,30 14 150 1,15 14 140
NORMAL 1,05 14 115 0,95 13 110
Technical data
Dimensions
width 44.5 cm
height 82 cm
depth 57 cm
Capacity 10 standard place-settings
Water supply
pressure 0,05 ÷ 1MPa (0.5 ÷ 10 bar)
7,25 – 145 psi
Power supply
voltage
See appliance data plate
Total absorbed
power
See appliance data plate
Fuse See appliance data plate
This dishwasher conforms to the
following European Community
Directives:
-2006/95/EC (Low Voltage
-2004/108/EC (Electromagnetic
Compatibility)
-2005/32/EC (Comm. Reg.
1275/2008) (Ecodesign)
--97/17/EC (Labelling)
-2002/96/ EC (Waste Electrical
and Electronic Equipment WEEE)
